1000L Tilting Vacuum Homogenizing Emulsifying Mixer Equipment For Cream Cosmetic

1.Main Boiler (Double Layer)

No

Item

Configuration and Parameters

Mark

1.1

Volume

Overall volume:1100L；Working Volume:1000L

Loading Coefficiency 0.8

1.2

Heating

Steam heating  Power:25KW

1.3

Basic Structure

Double Layer,Lifting cover,

tilte the tank to discharge,

scraped agitatorin the upperside,
Homogenizer lowerside

 1.4

Tank

Material contact later:SUS316L；

Thickness:6mm; Jacket 6mm;

Outer:SUS304,Thickness:2.5mm

Total Thickness:50mm

1.5

Cover

Material filter,Vacuum Pressure meter,

Vacuum Exhaust Valve,Vacuum Port,

sight glass light,Vision window,inlet,

perfume Hopper；

No Dead space,
Sanitory Valve

1.6

agitator

scraped

SUS316L

Stirring coefficiency:

Stirrer motor:2.6KW,Speed:0～63R/M；

Motor(SIEMENS),
Delta Converter

1.7

Homogeneous Way

Installation,internal circulation；

SUS316L

Homogeneous
coefficiency

Motor Power11KW,Rotating speed 3000R/M

Motor(SIEMENS)

Processing

Rotor and Stator in Wire cutting,assembled after polishing

Balance process axle

1.8

sealing

Burgmann Machinery Seal,Japan NSK Rolling Bearing；

1.9

polishing

In&outside hygiene grades,conforming GMP standard

S320U

2.Water Boiler

2.1

Volume

750L volume

Loading Coefficiency 0.8

2.2

Heating

Steam heating,Tap water cooling

Power 1.5KW

2.3

Construction

three layers,down stirring,Botton outlet

2.4

Material

Inner:SUS316,Thickness 3mm

SGS certificated

Jacket:Q235B 5mm thickness

Total Thickness:50mm

Outer shell: SUS304,2mm thickness

Heat Preservatory:Silicon Sulphate
