Tilting Vacuum Homogenizing Emulsifier Mixer, Emulsifying Equipment 1000L With Sight Glass

1.Main Boiler (Double Layer)

No

Item

Configuration and Parameters

Mark

1.1

Volume

Overall volume:1100L；Working Volume:1000L

Loading Coefficiency 0.8

1.2

Heating

Steam heating  Power:25KW

1.3

Basic Structure

Double Layer,Lifting cover,

tilte the tank to discharge,

scraped agitatorin the upperside,
Homogenizer lowerside

 1.4

Tank

Material contact later:SUS316L；

Thickness:6mm; Jacket 6mm;

Outer:SUS304,Thickness:2.5mm

Total Thickness:50mm

1.5

Cover

Material filter,Vacuum Pressure meter,

Vacuum Exhaust Valve,Vacuum Port,

sight glass light,Vision window,inlet,

perfume Hopper；

No Dead space,
Sanitory Valve

1.6

agitator

scraped

SUS316L

Stirring coefficiency:

Stirrer motor:2.6KW,Speed:0～63R/M；

Motor(SIEMENS),
Delta Converter

1.7

Homogeneous Way

Installation,internal circulation；

SUS316L

Homogeneous
coefficiency

Motor Power11KW,Rotating speed 3000R/M

Motor(SIEMENS)

Processing

Rotor and Stator in Wire cutting,assembled after polishing

Balance process axle

1.8

sealing

Burgmann Machinery Seal,Japan NSK Rolling Bearing；

1.9

polishing

In&outside hygiene grades,conforming GMP standard

S320U

2.Water Boiler

2.1

Volume

750L volume

Loading Coefficiency 0.8

2.2

Heating

Steam heating,Tap water cooling

Power 1.5KW

2.3

Construction

three layers,down stirring,Botton outlet
