Customized Rare Earth Bonded Neodymium NdFeB Magnets for Micro Motor, Car Seats

Customized Rare Earth Bonded Neodymium NdFeB Magnets for Micro Motor, Car Seats thumbnail-1
Customized Rare Earth Bonded Neodymium NdFeB Magnets for Micro Motor, Car Seats photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
YANSEN
Place of Origin:
China
Model Number:
Anisotropic Bonded Ferrite Ring & Rotor
Contact Supplier Request Quote Chat Now
Ningbo Yansen Enterprises Development Co., Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name YANSEN
Place of Origin China
Model Number Anisotropic Bonded Ferrite Ring & Rotor
Delivery Time:15-30 Days
Certification:ROHS, ISO9001, TS16949

Customized Rare Earth Bonded Neodymium NdFeB magnets for micro motor, car seats

Anisotropic bonded ferrite ring and rotor can be produced as different shapes with high precise dimensions, are widely applied for micro-motor, motors for car seats and wipers, automatic control parts and instruments etc..

Metal shaft or other insert with these injection ferrite can be made as any complicated shape, so as to meet customer\'s different demand.

CHARACTERISTIC TABLE

Grade TP-S62 TP-S65 TP-S67K DMS121 TP-F26S TP-A27E DMS221 TP-F76
Binder resin PA6 PA12 PPS
Magnetic properties  Remnant  induction Br mT (Gs) 239 2390 276  2760 288 2880 2850 280 2800 286 2860 2880 236  2360
Cohesive  force  Hcb KA/m (Oe) 171 2150 185 2330  182 2290 2350 185  2330 189  2370  2320 172 2160
Intrinsic Cohesive force Hcj KA/m (Oe) 235  2950 228  2860 217 2730 2990 224  2810 234  2940 2760 243 3060
Maximum  energy product (BH)max KJ/m³  (MGOe) 11.4 1.4 15.0  1.88 16.2 2.04 2 15.5 1.94  16.0  2.02  2.02 11.0 1.38
Physical  property Mold density g/cm³ 3.28 3.63 3.73 3.8 3.63 3.69 3.72 3.33
Melt flow Rate Ml g/10min 90 130 65 100 72 58 80 160
Condition 270℃ -10kg 270℃  -10kg 270℃ -10kg 270℃ -10kg 270℃  -10kg 270℃ -10kg 270℃  -10kg 330℃ -10kg
Flexual Strength MPa  (kg/cm²) 189  1930 167  1700 173 1760 　 125  1270 98 1000 　 149  1522
Flexural Modulus GPa  (kg/cm²) 15.9 1.62E+05 22.9 2.34E+05 26 2.65E+05 　 17.1  1.7E+05 10.4 1.1E+05 　 13.9 1.4E+05
Tensile Strength  MPa (kg/cm²) 102  1040 73  740 83.7  850 83.7 850 63.7 650 45.1  460 83.7  850 73.7 751
Elongation
