Custom Design Strong Bonded Ferrite Magnet Black Colored Self Adhesive Magnetic Sheet
Negotiable
/ Piece
1 Piece(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
OEM, ODM Anisotropic Injection Bonded Ferrite Ring and Rotor Round Shape for Instruments
-
Customized Rare Earth Bonded Neodymium NdFeB Magnets for Micro Motor, Car Seats
-
Magnetic Separation Roller for Fildys, Wire Pieces or Iron Abrasion DIA 200mm, 300mm
-
Customized or OEM Magnetic Separators Round Pipeline Drawer
-
Magnetic Square Pipeline Drawer Industrial Magnetic Separators Width 208 - 408mm
-
OEM Design Magnetic Liquid Filter Tank , Magnetic Separators Diameter 50 - 100mm
Product Details
| Brand Name | YANSEN | Place of Origin | China | |
| Model Number | Magnetic Sheets |
Product Description
Certification:ROHS, ISO9001, TS16946
Custom Design Strong Bonded Ferrite Magnet Black Colored Self Adhesive Magnetic Sheet
Magnetic sheet can be divided into three series as rolling magnetic sheet, cutting magnetic sheet and calendaring magnetic sheet. Rolling magnetic sheets have long length and flexible dimensions, easy to be packed and transported, also are easy to be processed by punching, calendaring and cutting etc., and adhesive tape and PVC material are easy to be covered on unmagnetization surface. Cutting magnetic sheets have length below 1m and have been cut into all kinds of dimensions. Calendaring magnetic sheets are usually made according to customer\'s special requirement and calendared by calender. They are widely applied for advertising, instruments, toys and all kinds of craftwork etc..
THE SIZE TOLERANCES OF MAGNETIC SHEETS:
| Length(L) | Tolerance | Width(W) | Tolerance | Height(H) | Tolerance |
| mm | mm | mm | mm | mm | mm |
| ≤20 | ±0.3 | ≤20 | ±0.3 | <1 | ±0.05 |
| >20-50 | ±0.5 | >20-50 | ±0.5 | ≥1-4 | ±0.1 |
| >50-100 | +1/0 | >50-100 | +1/0 | >4-6 | ±0.15 |
| >100-200 | +2/0 | >100-200 | +2/0 | >6-12 | ±0.2 |
| >200-300 | +3/0 | >200-300 | +3/0 | ||
| >300-400 | +4/0 | >300-400 | +4/0 | ||
| >400-600 | +6/0 | >400-600 | +6/0 | ||
| >600-800 | +8/0 | >600-800 | +8/0 | ||
| >800-1000 | +10/0 | ||||
| >1000 | +2%/0 |
Note: Tolerance can be modified according to customers\' special request.
MATERIAL CHARACTERISTICS:
| MODEL | DMS003 | DMS005 | DMS006 | ||
| Technical Parameters | Remnant induction Br | (T) | 190~230 | 210~250 | 240~270 |
| (Gs) | 1900~2300 | 2100~2500 | 2400~2700 | ||
| Cohesive force Hcb | KA/m | 111~143 | 128~160 | 151~183 | |
| (Oe) | 1400~1800 | 1600~2000 | 1900~2300 | ||
| Intrinsic Cohesive force Hcj | KA/m | 143~223 | 159~239 | 191~254 | |
| (Oe) | 1800~2800 | 2000~3000 | 2400~3200 | ||
| Maximum energy product(BH)max | KJ/m3 | 6.4~9.6 | 8~11.2 | 10.4~13.6 | |
| MGOe | 0.8~1.2 | 1.0~1.4 | 1.3~1.7 | ||
| Physical property | Tensile strength(kg/cm²) | ≥20 | ≥20 | ≥20 | |
| Hardness(A) | ≥96 | ≥96 | ≥96 | ||
| Density(g/cm³) | 3.6~3.8 | 3.6~3.8 | 3.6~3.8 | ||
| Temperature(℃) | –40~85 | –40~85 | –40~85 | ||
| Anti-ignition | v-0 | v-0 | v-0 | ||
