Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > Poly 40w Solar Panel
US$ 0.7/ - 0.7/
MOQ: 40 Pieces
Key Specifications
Get Latest Price
Brand Name:
Place of Origin:
China
Model Number:
WT poly 40w
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
Place of Origin
China
Model Number
WT poly 40w
| Maximum Power(W) | 40 W | |||
| Open circuit voltage(Voc) | 21.60V | |||
| Short Circuit Current(Isc) | 2.5A | |||
| Maximum Power Voltage(Vmp) | 17.64V | |||
| Maximum Power Current(Imp) | 2.3A | |||
| Solar Cell: | 156*52 Poly | |||
| Number of Cell(pcs) | 36 pcs | |||
| Brand Name of Solar Cells | ||||
| Size of Module(mm) | 680*524*30mm | |||
| Caple & Connector Type | Pass the TUV Certificate | |||
| Frame(Material Corners,etc.) | Aluminium-alloy | |||
| Backing (Brand Type) | TPT(made in China) | |||
| Cell Efficiency (%) | 13.7 | |||
| Maximum system voltage | 1000V | |||
| Weight Per Piece(KG) | 4.3 | |||
| FF (%) | 70-76 | |||
| Junction Box Type | Pass the TUV Certificate | |||
| Tolerance Wattage(e.g.5%) | ±3% | |||
| Front Glass Thikness(mm) | 3.2 | |||
| Temperature Coefficients of Isc(%) | 0.04 | |||
| Temperature Coefficients of Voc(%) | -0.38 | |||
| Temperature Coefficients of Pm(%) | -0.47 | |||
| Temperature Coefficients of Im(%) | 0.04 | |||
| Temperature Coefficients of Vm(%) | -0.38 | |||
| Temperature Range | -40°C to +85°C | |||
| Surface Maximum Load Capacity | 2400Pa | |||
| Allowable Hail Load | 23m/s ,7.53g | |||
| Bypass Diode Rating(A) | 12 | |||
