600kg Rated Capacity Suspended Elevators Installation Platform
- T/T L/C D/P D/A
- 7 days
You May Like
-
7.84KN Elevators Installation Platform With Speed YEJ100L-4 Motor
-
LTD8, LTD6, LTD5, LTD3 Hoist / Motor / Winch Suspended Platform Parts
-
30 kN / 800kg Safety Lock for Suspended Platform Parts
-
Electrical Suspended Platform Parts Control Box for Access Working Platforms
-
1.3 - 1.7 Suspended Platform Parts Metres Suspension Mechanism ( Parapet Clamp )
-
50 - 150 m 400kgs Pedal Suspended Working Platform Scaffold Systems
Product Details
| Brand Name | SHENXI | Place of Origin | China | |
| Model Number | ZLT600 |
Product Description
Certification:CE & SGS
600kg Rated Capacity Suspended Elevators Installation Platform
Descrition:
It is a kind of special suspended access equipment, powered by advanced motor systems. The double-floor structure helps carry more loads to better carry out the elevator installing and repair work
Features of ZLT600 Double Layer Suspended platform for Elevator Installation
-easy to handle and install
-no need to install extra scaffolding
-excellent working efficiency
- manufactured to the latest GB19155-2003 National Standard
- minimal space is required for transportation and storage
Specifications:
|
Name |
Parameters |
||
|
Rated Capacity |
600kg |
||
|
Rated Lifting Speed |
8-10m/min |
||
|
Platform DimensionL × W × H (mm ) |
1360╳1360╳3700 |
||
|
Wire Rope |
Special steel wire rope φ8.6 |
||
|
Hoist |
Rated Lifting Force |
7.84KN |
|
|
Motor |
Type |
YEJ100L-4 |
|
|
Power |
2.2KW |
||
|
Voltage |
380V |
||
|
Speed |
1420rpm |
||
|
Brake Torque |
15Nm |
||
|
Safety lock |
Permission Force of Impact |
30KN |
|
|
Lock justice point of view |
3°-8° |
||
|
Weight |
650kg |
||
|
Distance between main tracks (mm) |
L1≥1700mm |
||
|
Width of lifting machine room(mm) |
L2=2200-2400mm |
||
|
Distance between the top point and floor(mm) |
L3=1210mm |
||
