Brand Name
fidelix
Place of Origin
China
Model Number
FM25Q32A
32M-BIT
Serial Flash Memory with 4KB Sectors, Dual and Quad I/O SPI
FEATURES
■ SPI Flash Memory
-32M-bit / 4M–byte Serial Flash
-256-bytes per programmable page
-4K-bit secured OTP
■ Standard, Dual or Quad SPI
-Standard SPI: CLK, /CS, DI, DO, /WP, /Hold
-Dual SPI: CLK, /CS, IO0, IO 1, /WP, /Hold
-Quad SPI: CLK, /CS, IO0, IO1, IO2, IO3
■ High Performance
-104MHz clock operation
-208MHz equivalent Dual SPI
-416MHz equivalent Quad SPI
-50MB/S continuous data transfer rate
-31MB/S random access (32-byte fetch)
-Comparable to X16 Parallel Flash
■ Flexible Architecture
-Uniform Sector Erase (4K-byte)
-Block Erase (32K and 64K-bytes)
-Erase/Program Suspend & Resume
■ Endurance
-100K program/ erase cycles
■ Low Power Consumption
-Single 2.7 to 3.6V supply
-5mA active current
-<3μA Deep Power-down (typ.)
■ wide Temperature Range
--40℃ to +85℃ operating range
■ Advanced Security Features
-Software and Hardware Write-protect
-Top or Bottom, Sector or Block selection
-Lock-Down and OTP protection
■ Package Options
-8-pin SOIC 208-mil
-8-pad WSON 6x5-mm
-16-pin SOIC 300-mil
-8-pin DIP 300-mil
-8-pin VSOP 208-mil
- 24 ball TFBGA
■ Package Material
-Fidelix all product Green package
Lead-free & Halogen-free
RoHS Compliant
