NF F16-101/102 Fire Resistance Test for Railway Vehicles

Firetc fire test center will provide French Standard NF F16-101 Fire test to Railway Vehicles NFF16-101/102


 NF F16-101 - Railway Rolling Stock Fire Behavior Choice of Material

NF F16-102-Railway Rolling Stock Fire Behavior Choice of Material-Application for electrical equipment

The purpose of this standard is to propose a method of classification of materials for rolling stock obtained from the results of standardized tests. This method of classification establishes objectives and simultaneously takes into account as much the combustion of the materials as the opacity and toxicity of the combustion emissions.

NF F16-101 Fire test to railway vehicles-Standard Scope

The purpose of this standard is to establish rules relating to the choice of materials according to their fire behaviour with regard to reaction to fire, opacity of smoke and toxicity of gases emitted.

NF F 16-101 establish classification objectives and specifies the minimum classifications to be complied with according to the type of materials concerned.

NF F 16-101 is applicable to all non-metallic materials, with the exception of paintwork where they form part of passenger railcars, cabins, vans, observation railcars, wagons and their trailers, including drivers’ cabins where they exist as well as engine drivers’ cabins

NF F16-101 Fire test to railway vehicles-Fire Classification

Burning Behaviour I rating: I0, I1, I2, I3, I4

Burning Behaviour M rating: M0, M1, M2, M3, M4

Smoke and toxicity F rating: F0, F1, F2, F3, F4, F5

NF F16-101 Fire test to railway vehicles-Types of rolling stock

Category A1: All rolling stock, including drivers’ cabins, which travel frequently through tunnels

Category A2: Urban and suburban rolling stock, including drivers’ cabins, which travel infrequently through tunnels, wagons and their trailers, main-line sleeper cars.

Category B: Main-line rolling stock with seats, including drivers’cabins, which travel infrequently through tunnels, locomotive and locomotor drivers’ cabins,

NF F16-101/NF F 16-102 Fire test to railway vehicles-Reference Standard

ISO 4589-2: Plastics - Determination of burning behaviour by oxygen index - Part 2: Ambient - temperature test

NF EN 60695-2-1: Fire Hazard Testing

NF C20-455: Test methods-fire behaviour- Glow wire test-inflammability and ability to be extinguished

NF C32-070: Insulated conductors and cables for installation-Classification tests on conductors and cables with regards to fire behaviour

NF F16-102: Rolling stock -Fire Behaviour-Choice of materials, application to electrical equipment.

NF G07-128: Textiles-Fire Behaviour-Determination of oxygen number at room temperature

NF P 92-501: Buildings-Construction and furnishing materials-Rigid materials

NF P 92-503: Buildings-Construction and furnishing materials-Flexible materials

NF P92-507: Buildings-Construction and furnishing materials-Classification according to reaction to fire

NF T51-071: Plastics- Fire reaction tests-Determination of oxygen number

NF X10-702: Fire test methods-Smoke emission-Test of measurement of specific optical density of smoke by the combustion or the pyrolysis of solid materials

NF X65-010: Fire behaviour tests-General Principles

NF X65-012: Fire behaviour tests-Vocabulary

NF X70-100: Fire behaviour tests-Analysis of pyrolysis and combustion gases-Pipe still method

UIC 564-2: Rules relating to protection and fight against fire in railway vehicles in international service, carrying passengers or assimilated vehicles

For more detailed information about French Standard NF F16-101 fire test to Railway Components. Please contact on firetest@firetc.com.
