Product Details
Brand Name | Dragon | Place of Origin | China | |
Model Number | G-TK202 |
Product Description
Certification:CE, FCC, IP65
RTKe Embedded OS Waterproof IO Interface Vehicle GPS Tracking Systems
Water-proof casing design is a patent can prevent GPS device was damaged by into water, use aviation socket for IO interface, easy to connect with cables; CAN/485 BUS interface, easy to control vehicle; 1 route AD input interface can detect fuel consumption and temperature; especially suitable for engineering truck, special vehicle that run in severe environment.
Main features:
● Based international newest chip, double core structure, build-in RTKe OS, powerful.
● GPRSand SMS double channels, TCP and UDP double working mode
● Positioning based GPS reflected wave, assist with base station, strong capacity to prevent blocking to reduce the blind area
● Three proofing design, Quadruple protection for power source, 4 levels watchdog
● Anti-dismantle design for SIMcard
● Low power consumption
● Build-in high capacity backup battery
● CAN/485 BUS interface.
● It can update remotely, easy to maintain
● Approved by 3C, and approved by national grade quality authentication.
Product functions:
1.Signal detecting and control: 6 routes signal sensor, 7 vehicle status detecting, intelligence mode and forced mode to cut fuel/circuit; user-defined backup output control.
2. Alarm: 8 alarms, 3 modes of alarm.
3. Monitoring: vehicleautomatic tracking/monitoring, regions setting, geo-fence, GPS mileage statistics, blind area supplementary report, traces storage, base station positioning.
4. BUS communication: via CAN/485 BUS to achieve two ways communication between PLC controller and service center, real time monitor vehicle status and control vehicle.
5. Fuel consumption detecting: build-in AD input interface, equipped floater attenuation cable can measure fuel consumption.
6. Remote update: main device’s program was support to remote download; user can renew the program remotely.
7.Protection:
Power saving mode: in this mode, GPS device’s working current will drop to30mA@12V when vehicle was in flameout.
Car battery over discharge protection: it will switch to supply power by backup battery if car battery’s voltage is very low (10V).
Over voltage protection: it will cut the external circuit to protect GPS device if the voltage exceeds limit value (60V), backup battery can work for 3h.
Performance parameters:
|
Remark |
|||
Hardware framework |
Adopt double core chip, RTKe embedded OS |
|||
Communication module |
GPRS, SMS double channels module |
|||
Reliability design |
Quadruple protection for power source, 4 levels watchdog |
|||
PCB protection |
Three proofing protection |
|||
Water-proof design |
Water-proof design for casing, water-proof grade IP67 |
|||
Technical specifications |
||||
Working voltage |
10~60 V/DC |
|||
Limiting voltage |
100V/DC |
|||
Car battery protecting voltage |
Low: 10V(12V car battery)or 20V(24V car battery)high:60V |
|||
Power voltage of Anti-reversed connection |
≥100V |
|||
Average working current |
70mA DC 12V |
|||
Power saving mode |
<30mA DC 12V |
|||
