Hydraulic Bucking Unit

Hydraulic Bucking Unit thumbnail-1
Hydraulic Bucking Unit thumbnail-2
Hydraulic Bucking Unit photo-1
Hydraulic Bucking Unit photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
sj-drilling
Place of Origin:
China
Model Number:
YCJ
Contact Supplier Request Quote Chat Now
Hei Longjiang North Shuangjia Drilling Tools Co., Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name sj-drilling
Place of Origin China
Model Number YCJ
        Hydraulic bucking unit is an important equipment to make up, break out and maintain drilling tool, pipe string or the thread connection of downhole tool in petroleum exploration. Considering the current state of petroleum industry, our YCJ—25 hydraulic bucking unit absorbed the advanced technology of foreign product and  priored to other same product at home. The platform had compact design. Surface of the platform is made of operating handle, torque metre and hydraulic pressure gauge. The bottom of surface is hydraulic pipeline, the end is electric hydraulic pump.

 The product possessed some advantages.
a.High level automation and easy operation.
b.Two persons can accomplish the make-up/break-out of tools.
c.High pulling torque when making up.
d.Adapted to wide range diameter
e.Quick spinning and axial thrust
f.Do not need to change tong head while using.

1.Dynamo:Power 15KW   RPM  1460r/min
2.Hydraulic System:
Fuel tank capacity:630L
System Pressure:Max.Working Pressure 20Mpa
Hydraulic Operational Control Console: Length×Width×Height: 1500×750×800mm
3.Break-out diameter Range:63-350mm
4.Spinning Mainframe:
Nominal break-out torque:5KN.m-250KN.m Nominal make-up torque:5KN.m-200KN.m
Six Cylinder Clamp speed:0.6m/min        Torque Resolution:0.2 KN·m
5.Break-out Mechanism:Max.Single Clamp Force:200KN
6.Tailstock Pull and Push System(Resolution:0.2 KN.m):
Max.Thrust of Tailstock:180KN       Max.Pull of Tailstock:143KN
Oil Cylinder Stroke:0~1.5m      Speed of Oil Cylinder:0~6m/min
Pull and Push Track::Tailstock Track 7.4m
Support Unit:
Moveable Support Unit: two sets    Stock Support Unit: two sets   Spinning Bracket:one set
7.Spinning System:
Spinning Torque:2 KN.m~4 KN.m      Suitable Diameter:63~350mm
8.Bracket:All brackets take hydraulic bracket, we can control the rise and fall of bracket through the platform.
9.Fittings: Service Tool:1 set         Sealing Bonded Washer:12 sets
If you have different requirement, we will try our best make you content through mutual negotiation.
