Help CenterDiesel Forklift Truck
Related Products
-
Electric/Battery Forklift TruckNegotiableMOQ: 1 Set -
Gasoline/LPG Forklift TruckNegotiableMOQ: 1 Set
-
Skid Steer LoaderNegotiableMOQ: 1 Set
-
Different Capacity Off-Road Forklift With Assistive DevicesNegotiableMOQ: 1 Set
-
CQD20EH-120 Braking Electromagnetic Electric Telescopic Traction Forklift Bearing 1.5T 2TNegotiableMOQ: 1
Load capacity: 3000kg
Load center: 500mm
Max. Lifting speeds (full load): 400mm/s
Max. Driving speeds: 18/20km/h
Drawbar pull: 10, 000N
Gradeability: 15/20%
Lifting height: 4, 500mm
Free lift: 1270mm
Tilting angles (forward - backward): 6 / 12
Min. Turning radius: 2, 700mm
Angle stacking aisle: 2, 550mm.
Min. Under-clearance: 135mm
Overall length: 3, 820mm
Overall width: 1, 228mm
Overall height (with mast retracted): 2, 110mm
Overall height (with mast extended): 5, 770mm
Overall height to overhead guard: 2, 120mm
Wheel base: 1, 700mm
Front tread: 1, 000mm
Rear tread: 970mm
Front tyre: 28x9-15 PR
Rear tyre: 6.5 - 10 PR
Total weight: 4480kg.
Fork width: 125mm
Fork thickness: 45mm
Backrest height: 1, 195mm
Fork length: 1220mm
Engine model: 490BPG made in China, imported engine ISUZU 4JG2PE-01 optional
Rate power: 37kW
Rotate Speed at rate power: 2, 650rpm
Max. Torque: 145N. M
Rotation speed at max. Torque: 1, 800-1900rpm
Power shift: Tor-con
Packing Details: 3 PCS/20CTN & 5PCS/40CTN.
