rubber powder line had passed BV authentication.
Including ring cutter,strips cutter,blocks cutter,steel wire separator etc.
Good quality with reasonable price. Easy operation with convenient maintenance. Low labor intensity and low energy consumption.
1. Tyre recycling machine, tyre ring cutter, rubber crusher, shredder magnet for steel and fiber seperator.
2. Version: GY30
3. Pull the wire directly from tyre, then first crack whole tyre into small size 5*5 mm, then middle crack, finally grind it into 20-120mesh powder
4. The whold process is automatic, and easy to operate.
5. Small noise and no polution.
6. we export rubber machines to all the world, such like south Asia, south America, Africa etc.
7. ISO9001, SGS & CE certificate
|
Type Technical parameter |
XKP-400 |
XKP-450 |
XKP-560 |
| Front roll diameter(mm) | 400 | 450 | 560(510) |
| Rear roll diameter(mm) | 400(Groove roller) | 450(Groove roller) | 510(560)(Groove roller) |
| Working length of rolls(mm) | 600 | 650 | 800 |
| Front roll surface speed(m/min) | 17.32 | 23.2 | 25.56 |
| Friction ratio | 1: 1.38 | 1: 1.38 | 1: 1.30 |
| Max. nip(mm0 | 8 | 8 | 15 |
| Motor power | 45 | 55 | 75(90) |
| Output per hour(kgs) | 150-200kgs | 250-300kgs | 450-500kgs |
| Types of motor | Y315M-6 | Y315M-6 | Y315M-6 |
| GEAR BOX -TYPE AND SIZE | Nylon bush | Planet gear box NGW122 | Planet gear box NGW122 |
| BEARING TYPE | nylon | nylon | bearing |
| Overall dimension: length× Width× Height(mm) | 3950× 1800× 1780 | 4770× 1846× 1835 | 5064× 2284× 1978 |
| PRICE USD/SET | 14500 | 21500 | 34500 |
Our motto: The honesty is the root, a promise is a promise.
