Product Name: LED Mini Chip RGB Tube
Model: IMG-MT15RGB-S
LED Brand: Epistar
Input Voltage: 12VDC
Working Temp.: -20°c~50°c
LED Strips Features
1. Mini Chip RGB Tube adopts Chip RGB Led as its luminous body. Beaming angle is 120° specs for selection: 15 LEDs (12 VDC). These Leds are evenly set on the PCB board. Its colour is soft and well-mixed. Four wires, each bar could be connected together via male and female connectors.
2. LEDs of this product are from famous international company.The luminous body is of high intensity,large viewing angle, good quality and stability.
3.φ16 transparent cylindric housing protects LEDs and PCB board from being polluted by dust and damaged by something else without affecting the light effects. Its protection class is IP44. The tube can be rotated at will to adjust direction of light with matched semicircular holder on both ends.
4. Power Consumption: 3.6W/0.5M(12VDC)
5. Led Spacing: 33mm(IMG-MT15RGB-S)
6. When controlled by DMX512 controlling system, it can realize many changing effects of multi-color jumping, gradual color changing, etc. It also can be controlled by RGB controller IMG-CT308 to realize whole color changing.
7. Package Info:Ctn size: 58*27*36cm, 120pcs/ctn, Gross Weight: 11.5KG/ctn,Volumetric Weight: 12KG/ctn.
8. It is mainly for indoor application, such as small floodlight, cove lighting, stair decoration, edge lighting, etc.
9. Warranty: 18 months.
LED Strips Instruction
Mini Chip RGB Tube 12VDC adopts 15pcs high brightness Chip RGB SMD LED as its luminous body The LEDs are set evenly on the PCB board, whose color is soft and well-mixed. Both ends with male or female connectors.
The transparent PC housing can protect the PCB board and LEDs from being polluted by dust and damaged by something else. The protection class is IP44. The tube can be rotated at will to adjust direction of light with matched semicircular holder on both ends.
When controlled by DMX512 controlling system, it can realize all kinds of changing effects, such as multi-color jumping, gradual color changing, rainbow, etc. It also can be controlled by RGB Controller common positive to realize whole color changing. It can be widely used for indoor decoration, such as cove lighting, edge ligting, etc.
Specification:
Size: φ16mm*520mm
Weight:72g
Beaming angle:>120degree
LED Spacing:20 mm
Electric Specs:
IP Class:IP44
Power consumption:3.6W(12VDC);
Power supply(12VDC):
Waterproof 30W-12V-2.5A;
60W-12V-5A;150W-12V-12.5A
Non-waterproof 55W-12V-4.6A,
150W-12V-12.5A ; 300W-12V-25A
