We offer DIN 17155 HII steel plate/sheet for boiler steels:
1.Equivalent grades:
EN 10028-2 P265GH ,NFA 36-205 A 42 CP,UNI 5869 Fe 410-1KW,BS 1501 161 Gr.400/164 Gr.400/224 Gr. 400,UNE 36087 A 42 RCI,ASTM A 414 Gr. E / A 516 Gr. 60
2. Chemical composition:
C : ≤ 0.2 Si:≤ 0.4 Mn:0.8-1.4 S :≤0.015 N:≤ 0.012 Cu:≤ 0.30 AL:≤ 0.02
P :≤0.025 Cr:≤0.30 Ni:≤0.30 Mo:≤0.08 Nb : ≤ 0.2 Ti:≤ 0.3. V:≤ 0.3
3.Mechanical properties:
Tensile Strength σb(MPa) :
410-530(thickness under 100mm);
400-530(thickness between 100-150mm);
390-530(thickness between 150-250mm)
Yield Strength σ0.2 :
≥265(thickness under 16mm);
≥255(thickness between 16-40 mm);
≥245(thickness between 40-60mm);
≥215(thickness between 60-100mm);
≥200(thickness between 100-150mm);
≥185(thickness between 150-250mm)
Elongation δ5(%) : ≥ 22
Impact Energy (KV J) :
≥27(under -20 degree );
≥34(under 0 degree );
≥40(under 20 degree )
4. HII steel plate/sheet is one mainly of Steel for gas cylinders and gas vessels.DIN 17155 HII steel grade is for heat resistant plates.
If you have any problem, please be free to contact us:
Tel:0086-371-86151827
Fax:0086-371-86011881
lotus@bebonchina.com
