Home > Manufacturing & Processing Machinery > Metallic Processing Machinery > Metal Forging Machinery > CNC Hydraulic Drop Forging Hammer
US$ 20000 - 2000000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
anyang
Place of Origin:
China
Model Number:
C92K-16
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
Brand Name
anyang
Place of Origin
China
Model Number
C92K-16
CNC Hydraulic Die Forging Hammers are widely applied in automobile forgings, motorcycle forgings, hardware forgings, hand tools blank forgings, stainless steel tableware, and aeronautic forgings etc, especially for the precision forging field. CNC hydraulic die forging hammer complied with low carbon production, low hammer running cost production and high efficiency production etc high requirements in modern forging industry.
Features:
1. Programmable hitting
2. Precise energy control
3. High forging accuracy
4. High blow frequencies
5. Simple and safe operating
6. Low forging vibration
7. Optimum die life and hammer rod life
8. Realize automatic production line
| MODEL | C92K-12.5 | C92K-16 | C92K-20 | C92K-25 | C92K-31.5 | C92K-40 | C92K-50 | C92K-63 |
| Hit energy(KJ) | 12.5 | 16 | 20 | 25 | 31.5 | 40 | 50 | 63 |
| Weight of falling parts(kg) | 860 | 1080 | 1350 | 1700 | 2150 | 2700 | 3400 | 4300 |
| Max hit number(min-1) | 129 | 122 | 123 | 113 | 100 | 98 | 98 | 98 |
| Hit stroke(mm) | 420-620 | 435-635 | 455-665 | 470-685 | 490-755 | 510-790 | 530-775 | 550-805 |
| Working oil pressure(Mpa) | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 |
| Main motor power(KW) | 37 | 45 | 55 | 75 | 75 | 90 | 2*75 | 2*75 |
| Machine weight(kg) | 19000 | 24000 | 30000 | 41000 | 46000 | 58000 | 80000 | 94000 |
| MODEL | C92K-80 | C92K-100 | C92K-125 | C92K-160 | C92K-200 | C92K-250 | C92K-320 | C92K-400 |
| Hit energy(KJ) | 80 | 100 | 125 | 160 | 200 | 250 | 320 | 400 |
| Weight of falling parts(kg) | 5400 | 6800 | 8500 | 10800 | 13700 | 17100 | 21000 | 27000 |
| Max hit number(min-1) | 92 | 81 | 70 | 70 | 60 | 50 | 45 | 40 |
| Hit stroke(mm) | 570-835 | 595-885 | 615-920 | 640-960 | 740-1060 | 770-1100 | 740-1150 | 860-1200 |
| Working oil pressure(Mpa) | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 |
| Main motor power(KW) | 2*90 | 2*90 | 2*110 | 3*90 | 2*160 | 2*160 | 2*200 | 4*160 |
| Machine weight(kg) | 116000 | 141000 | 189000 | 235000 | 275000 | 342000 | 445000 | 530000 |
