Q35Y Hydraulic Iron Worker Machine/ironworker Machine/punching and Shearing Machine
US$ 5000 - 5000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Besco
Place of Origin:
China
Model Number:
Q35Y
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Hydraulic Ironworker/ Ironworker/ Iron WorkerUS$ 5000 - 5000MOQ: 1 Set -
Cut to Length Line,coil Cutting Line,steel Coil Cut to Length LineUS$ 5000 - 5000MOQ: 1 Set
-
Pittsburgh Lock Machine/lock Forming Machine/Lock FormerUS$ 5000 - 5000MOQ: 1 Set
-
TDF Flange Forming Machine,flange Forming Machine,forming MachineUS$ 5000 - 5000MOQ: 1 Set
-
Press Break/hydraulic Press Break/press Break MachineUS$ 5000 - 5000MOQ: 1 Set
Brand Name
Besco
Place of Origin
China
Model Number
Q35Y
1,Q35Y Hydraulic Iron worker Machine/ironworker machine/punching and shearing machine
2, CE certification 3, Multi-functions
4, Functions optional
5, one year qaulity guarantee
Features of Q35Y Hydraulic Iron worker Machine/ironworker machine/punching and shearing machine
1, Besco Q35Y Hydraulic Iron worker Machine/ironworker machine/punching and shearing machine adopt shydraulic driving system.
2, Besco Q35Y Hydraulic Iron worker Machine/ironworker machine/punching and shearing machines are the latest iron workers in China.
3, Various metal plate, square bar, round bar, angle, channel and joist can be cut, punched and notched on the Q35Y Hydraulic Iron worker Machine/ironworker machine/punching and shearing machine
.
.
4, Besco Q35Y Hydraulic Iron worker Machine/ironworker machine/punching and shearing machine is also equipped with a stop device for cutting.
a, Punching.
Full range of universal punches and dies are available unique style allows for large angle iron punching and large channel punching.Lare viewing window on stripper swing away design for ease of operation. larege two piece gauging tablewith rulers and stop as standard fitting. Quick change coupling nut and sleeve for rapid replacement of change.
b, Shearing
Round and square bar shear has multiple hoes for a variety of sizes. Adjustable hole down device for round/square bar, channel/beam cutting.
c, notching
Unique design allows for cutting of angle and flat bar.
D, Bending
Can also bend the plate below 500mm
| Specification | Q35Y-16 | Q35Y-20 | Q35Y-25 | Q35Y-30 |
| Pressure (Ton) | 55 | 75 | 110 | 140 |
| Max.Shear thickness (mm) | 16 | 20 | 25 | 30 |
| Plate Strength (N/mm2) | 450 | 450 | 450 | 450 |
| Shear Angle (degree) | 7 | 8 | 8 | 8 |
| Shear Size (H*W)(mm) |
16*250
8*400
|
20*330
10*480
|
25*330
16*600
|
30*335
20*600
|
| Stroke Travel (mm) | 80 | 80 | 80 | 80 |
| Stroke Time (times/min) | 8 | 8 | 6 | 6 |
| Throat Depth (mm) | 300 | 355 | 400 | 600 |
| Punching Thinckess (mm) | 16 | 20 | 25 | 26 |
| Max.punching Diameter (mm) | 25 | 30 | 35 | 381` |
| Main Motor Power (kg) | 4 | 5.5 | 7.5 | 11 |
