TPV DC/DC Converters Power Supply Module
US$ 0.22
≥555555555555777800 Pieces
Key Specifications
Get Latest Price
Place of Origin:
China
Model Number:
TPV 5V, 12V & 15V Series
Payment & Shipping
Payment Methods:
Port of Shipment:
GZ
Delivery Detail:
7 days
Related Products
-
TPV 24V & 48V Series DC/DC Converter Power Supply ModuleUS$ 0.19MOQ: 2147483647 Pieces -
Sell DC/DC Converters TP2D2412-3W Power Supply ModuleUS$ 0.22MOQ: 2147483647 Pieces
-
Sell DC/DC Converters/TPJ1205SA-5KVDC Isolation Power SupplyUS$ 0.27MOQ: 2147483647 Pieces
-
DC-DC Converters / TPD / 1W / Twin Output Power Supply ModuleUS$ 0.22MOQ: 2147483647 Pieces
-
Sell Dc-dc Converter TKE0303D-1W Power Supply ModuleUS$ 0.19MOQ: 2147483647 Pieces
Place of Origin
China
Model Number
TPV 5V, 12V & 15V Series
| Summary Description: | ||||||||||||
|
1W 3kVDC Isolated Single & Dual Output DC/DC Converters power supply module The TPV series of industrial temperature range DC/DC converters are the standard building blocks for on-board distributed power systems. They are ideally suited for providing local supplies on control system boards with the added benefit of 3kVDC isolation . Available in SIP and DIP with dual and single output pinout. | ||||||||||||
| Basic Terms: | ||||||||||||
| 1 | Type | TPV 5V, 12V & 15V Series | ||||||||||
| 2 | Efficiency | to 80% | ||||||||||
| 3 | Power density | 0.85W/cm3 | ||||||||||
| 4 | Isolation voltage | 3kVDC isolation (1 minute) | ||||||||||
| 5 | Related certificate | RoHS compliant | ||||||||||
| 6 | Wide temperature | at full 1 Watt load, –40°C to 85°C | ||||||||||
| 7 | Package material | UL 94V-0 package material | ||||||||||
| 8 | Input voltage | 5V, 12V, 15V | ||||||||||
| 9 | Output voltage | 5V, 9V, 12V, 15V | ||||||||||
| 10 | MOQ | 1 pc (no ltimited for considered the long coorperation relations) | ||||||||||
| 11 | Terms of payment | Western Union,T/T | ||||||||||
| 12 | Terms of delivery | DHL / UPS / EMS / TNT | ||||||||||
| 13 | Delivery time | 7-12 working days | ||||||||||
Part Number |
Nominal Input Voltage |
Output Voltage |
V |
V |
|
TPV2405DA |
24 |
5 |
TPV2409DA |
24 |
9 |
TPV2412DA |
24 |
12 |
TPV2415DA |
24 |
15 |
TPV2403SA |
24 |
3.3 |
TPV2405SA |
24 |
5 |
TPV2409SA |
24 |
9 |
TPV2412SA |
24 |
12 |
TPV2415SA |
24 |
15 |
TPV2424SA |
24 |
24 |
TPV4805DA |
48 |
5 |
TPV4809DA |
48 |
9 |
TPV4812DA |
48 |
12 |
TPV4815DA |
48 |
15 |
TPV4803SA |
48 |
3.3 |
TPV4805SA |
48 |
5 |
TPV4809SA |
48 |
9 |
TPV4812SA |
48 |
12 |
TPV4815SA |
48 |
15 |
TPV2405D |
24 |
±5 |
TPV2409D |
24 |
±9 |
TPV2412D |
24 |
±12 |
TPV2415D |
24 |
±15 |
TPV2405S |
24 |
±5 |
TPV2409S |
24 |
±9 |
TPV2412S |
24 |
±12 |
TPV2415S |
24 |
±15 |
TPV4805D |
48 |
±5 |
TPV4809D |
48 |
±9 |
TPV4812D |
48 |
±12 |
TPV4815D |
48 |
±15 |
TPV4805S |
48 |
±5 |
TPV4809S |
48 |
±9 |
TPV4812S |
48 |
±12 |
TPV4815S |
48 |
±15 |
