Help CenterPVC Cover Flexible Conduit
Negotiable
MOQ: 5000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
LEINUOER
Place of Origin:
China
Model Number:
LNE-JSB
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
Brand Name
LEINUOER
Place of Origin
China
Model Number
LNE-JSB
Product code: LNE-JSP
Product material: (inner layer) adopting galvanized steel band with special insulation treatment (outer layer) adopting PVC raw material (anti-UV, anti-aging)
Working temperature: -10℃~+80℃, instantaneously can be +100℃
Property:
1. The flexible pipes have extremely good waterproof, insulating and pull resistance.
2. The thickened surface is made of PVC.The surface is smooth.The PVC plastic is added with fire retarding agent.
3. The structure is buckle structure, which enhances the pull resistance and is not liable to crack or deform.
4. Extremely soft with good bending performance. The inner smoothness makes the entry of wires very easy.
Application: Used for wire protection at railways, engines, traffic system engineering, air-conditioners, various machineries,power plants, chemical industries, power distribution system, communication system, vessels, mansions, factory buildings as well as the outdoors’ exposed locations.
Usage: protecting wires/cables and provide insulation and waterproofing performance.
How to use: Put the wires/cables through the pipes before fitting correspondent type of LNE-DPJ joints. Item No.
Product material: (inner layer) adopting galvanized steel band with special insulation treatment (outer layer) adopting PVC raw material (anti-UV, anti-aging)
Working temperature: -10℃~+80℃, instantaneously can be +100℃
Property:
1. The flexible pipes have extremely good waterproof, insulating and pull resistance.
2. The thickened surface is made of PVC.The surface is smooth.The PVC plastic is added with fire retarding agent.
3. The structure is buckle structure, which enhances the pull resistance and is not liable to crack or deform.
4. Extremely soft with good bending performance. The inner smoothness makes the entry of wires very easy.
Application: Used for wire protection at railways, engines, traffic system engineering, air-conditioners, various machineries,power plants, chemical industries, power distribution system, communication system, vessels, mansions, factory buildings as well as the outdoors’ exposed locations.
Usage: protecting wires/cables and provide insulation and waterproofing performance.
How to use: Put the wires/cables through the pipes before fitting correspondent type of LNE-DPJ joints. Item No.
| Item No. | Specifications | Outer diameter and tolerance | Natural curve | Max. axial pull | Packaging unit (meter) | |
|---|---|---|---|---|---|---|
| Metric | G system | |||||
| LNE-SL-MT-6 | Φ6 | 3/16″ | 9.00±0.25 | 40 | 335 | 200 |
| LNE-SL-MT-8 | Φ8 | 5/16″ | 11.8±0.30 | 45 | 470 | 200 |
| LNE-SL-MT-10 | Φ10 | 1/4″ | 14.5±0.30 | 55 | 590 | 100 |
| LNE-SL-MT-12 | Φ12 | - | 16.5±0.35 | 60 | 710 | 100 |
| LNE-SL-MT-13 | Φ13 | 3/8″ | 17.5±0.35 | 65 | 765 | 100 |
| LNE-SL-MT-15 | Φ15 | - | 20.2±0.35 | 80 | 885 | 100 |
| LNE-SL-MT-16 | Φ16 | 1/2″ | 21.2±0.35 | 85 | 940 | 100 |
| LNE-SL-MT-19 | Φ19 | - | 24.5±0.40 | 95 | 1120 | 50 |
| LNE-SL-MT-20 | Φ20 | 3/4″ | 25.5±0.40 | 100 | 1180 | 50 |
| LNE-SL-MT-25 | Φ25 | 1″ | 31.7±0.45 | 120 | 1450 | 50 |
| LNE-SL-MT-32 | Φ32 | 1 1/4″ | 39.6±0.50 | 150 | 1885 | 25 |
| LNE-SL-MT-38 | Φ38 | 1 1/2″ | 46.6±0.60 | 180 | 2240 | 25 |
| LNE-SL-MT-51 | Φ51 | 2″ | 59.5±1.00 | 220 | 3000 | 20 |
| LNE-SL-MT-64 | Φ64 | 2 1/2″ | 73.5±1.50 | 310 | 3770 | 10 |
| LNE-SL-MT-75 | Φ75 | 3″ | 84.5±2.00 | 350 | 4405 | 10 |
| LNE-SL-MT-100 | Φ100 | 4″ | 109.0±3.0 | 410 | 4700 | 10 |
