Sell OLT1550B Series External Modulation Optical Transmitter

Model No.:OLT1550B
Product Origin:China
Brand Name:
Price Terms:FOB Shanghai
Payment Terms:
Certification:ISO9001:2000, CCC
Description:Features 1. Adopting imported laser as signal source 2. Adopting high-linearity external modulator to control the signal. 3. Adjustable SBS (13dBm,16dBm,18dBm). 4. Intelligent shell could control the temperature automatically. 5. Two powers taking the part of hot backup and cold backup respectably. Technical Parameters Optical Wavelength 1550±10nm Output Power 2x7dB Connector Type FC/APC SC/APC SU/UPC Relative Noise Density ≤160dB/H2 SBS Suppression Threshold 13dBm, 16dBm,18dBm Operating Bandwidth 45-862MHz RF input Return Loss ≤16dB Power supply 90-265V Flatness ≤±0.75dBm Products Series OLT1550-1x5(One Outputs≥5dBm) OLT1550-1x6(One Outputs,≥6dBm) OLT1550-1x7(One Outputs,≥7dBm) OLT1550-1x8(One Outputs,≥8dBm) OLT1550-1x9(One Outputs,≥9dBm) OLT1550-2x5(One Outputs,≥5Bm) OLT1550-2x6(Two Outputs,≥6dBm) OLT1550-2x7(two Outputs,≥7dBm) OLT1550-2x8(Two Outputs,≥dBm) OLT1550-2x9(Two Outputs,≥9dBm) OLT1550-2x10(Two Outputs,≥10dBm) OLT1550-2x11 (Two Outputs,≥11dBm)
