Axial Flow Pump (Submersible Propeller Pump)
US$ 200 - 5000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
GanQuan
Place of Origin:
China
Model Number:
QZB
Payment & Shipping
Payment Methods:
Port of Shipment:
XingGang
Delivery Detail:
30 days
Related Products
-
Tubular Flow PumpUS$ 200 - 1000MOQ: 1 Set -
Axial Flow Pump-Sleigh Floating TypeUS$ 100 - 500MOQ: 1 Set
-
Submersible Sewage PumpUS$ 200 - 500MOQ: 1 Set
-
Submersible Borehole Pump (deep Well Water Pump)US$ 100 - 500MOQ: 1 Piece
-
High-Quality Self-Priming Chemical Axial Flow Magnetic Oil Pump for Industrial UseNegotiableMOQ: 10 Bags
Brand Name
GanQuan
Place of Origin
China
Model Number
QZB
Application
Submersible
Fuel
Other, No
Power
Electric
Usage
Water
Theory
Axial Flow Pump
Standard or Nonstandard
Standard
Structure
Single-stage Pump
Pressure
Low Pressure
Appropriate for pumping clear water or lightly contaminated water. Used to flood to flood control and drainage farmland irrigation, water supply projects, etc.
Power: 22 to 500 KW
Discharge: 500 to 20000 m3/h
Head: 1.5 to 15 m (3.6- 54 feet)
Pump Outlet Diameter: 350 to 1400mm (13.7 to 55.1 inch)
Dia. Of Impeller: 267 to 1540mm (10.5 to 60.6 inch)
Rotate Speed: 485 to 1450 r/min
Angle of Impeller Installation: from -6 deg. to +6 deg.
Ph Value: 6, 9
Operating limits:
Maximum ambient temperature 50 deg. C
Motor:
1. Rewindable, dry-type, whole sealing and three-phase asynchronous motor
2. Insulation Grade: F
3. Protection Grade: IP68
4. Double/Triple mechanical sealing
5. Equipped with special control cabinet
6. Voltage: 380-10000V
7. Frequency: 50; 60Hz
Materials:
1. Pump body: cast iron
2. Impeller: stainless steel
3. Shaft with rotor: 45 steel
Advantages:
1)The integration of pump body and motor without other assembly process
2)Saving price 30 to 40% comparing with the ground sewage pump station with the civil and structural engineering.
3)Lower noise and underground pump station.
4)Easy, reliable and steady operation, realizing remote control.
5)Greater weight for same bulk
6)Completely meeting power standard by testing
Mixed Flow Pump
Appropriate for pumping clear water or lightly contaminated water. Used to flood to flood control and drainage farmland irrigation, water supply projects, etc.
Flow: 500-45000m3/h
Lift: 1.5-20m
Power: 22-800kW
Diameter: 350-1600mm
Voltage: 380v; 6kv; 10kv
Send Inquiry to This Supplier
Business Type
Manufacturer
Year Established
1985
Annual Export Value
US$50 Million - US$100 Million
Port of Shipment
XinGang
