Crosse Roller Rotary Table Bearing Bearing Slewing Bearing XU120222

Crosse Roller Rotary Table Bearing Bearing Slewing Bearing XU120222 thumbnail-1
Crosse Roller Rotary Table Bearing Bearing Slewing Bearing XU120222 photo-1
US$ 290 - 300 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
NTL
Bore Size:
140,
Outside Diameter:
300,
Contact Supplier Request Quote Chat Now
Changsha Terry Machinery Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name NTL
Bore Size 140,
Outside Diameter 300,
Model Number XU120222
Precision Rating P0
Seals Type Sealed
Number of Row Single Row
Place of Origin Henan, China

Crossed roller rotary table bearing bearing slewing bearing XU120222





RU series high-rigidity cross roller bearings as the inner and outer rings are used in the overall structure, with high rigidity, and with a mounting hole, the installation does not require a fixed flange and bearing, a large degree of simplification of the installation process, and does not affect the installation accuracy, With a high degree of rotation accuracy and greater torque, but also can be based on precision requirements free to choose the inner ring or outer ring rotation, with a greater degree of freedom of choice.



single-row crossed roller slewing ring is composed of two seat-rings.It features compact in design,light in weight,high precision and small fitting clearance. As the rollers are 1:1cross aranged,it is suitable for high precision mounting and capable to bear axial force,rsultant moment and considerable large radial force. The single-row crossed roller slewing rings are widely used for hoisting,transporting,engineering machines machine tool applications such as vertical boring mills, vertical grinding machines, and other similar applications. as well as for military products.





Cross roller bearing is a compact structure bearing with orthogonally arranged cylindrical rollers; it has high rotation accuracy capable of bearing loads in every direction.



With the cross-roller ring, cylindrical rollers are arranged crosswise, with each roller perpendicular to the adjacent roller, in a 90°V groove, separated from each other by a spacer retainer. This design allows just one bearing to receive loads in all directions including, radial, axial and moment loads. Since the Cross-Roller Ring achieves high rigidity and the precision can reach up to P5,P4,P2, despite the minimum possible dimensions of the inner and outer rings.





 Identification number
 Main dimensions    Basic load rating(radial)  weight

Basic load rating(axial)
    inner ring   outer ring  Roller pitch circle diameter  width φLa mounting hole φLi mounting hole Ca C0a Cr Cor Kg

d D dp B na ni KN KN KN KN

(mm) (mm) (mm)  (mm)
XU050077 40 112 77 22 97 6-φ6.6 56 6-M8 22.4 29 14.3 14.2 1.4
XU060094 57 140 94 26 120 6-φ9 70 6-M8 32.5 37.5 20.7 18.4 2.4
XU060111 76.2 145.79 111 15.87 133.1 8-φ6.9 88.9 8-φ6.9 36 44.5 22.8 21.5 1.2
XU080120 69 170 120 30 148 6-φ9 90 6-M8 56 53 35.5 26 4
XU080149 101.6 196.85 149.6 22.22 177.8 16-φ6.9 115.8 16-φ6.9 63 66 40 32.5 3.6
XU120179 124.5 234 179 35 214 12-φ11 144.5 12-φ11 118 179 75 88 7
XU120222 140 300 222 36 270 12-M16 170 12-φ18 133 275 85 131 12
XU160260 191 329 260 46 305 20-φ14 215 20-φ14 212 350 135 173 16
XU080264 215.9 311 264 25.4 295.3 12-φ8.7 231.8 12-φ8.7 85 117 54 57 6.9
XU160405 336 474 405 46 450 30-φ14 360 30-φ14 270 550 172 270 25
XU080430 380 480 430 26 462 20-φ9 398 20-M10 110 280 70 138 12
XU300515 384 646 515 86 598 18-φ26 432 18-φ26 720 1370











Crosse roller rotary table bearing bearing slewing bearing XU120222



Crosse roller rotary table bearing bearing slewing bearing XU120222Crosse roller rotary table bearing bearing slewing bearing XU120222Crosse roller rotary table bearing bearing slewing bearing XU120222



Crosse roller rotary table bearing bearing slewing bearing XU120222



Crosse roller rotary table bearing bearing slewing bearing XU120222



Crosse roller rotary table bearing bearing slewing bearing XU120222



If you are interestes,feel free to contact with us!



Skype:xieyuyun103



Whatsapp:008613667367982



Tel:+86 13667367982
