The internal structure of the insert ball bearing is the same with that of deep groove ball bearing. But the inner race of this bearing is wider than the outer race. The outer race has the spherical surface. Insert ball bearings can self aligning with the fit between the outer race and the bearing block. Insert ball bearings are compact. It’s easy for loading and unloading. Spherical insert ball bearings often used in mining, metallurgy, textile, transportation machinery, etc.
We are producing UC NA SB SA UEL 200 and 300 inserted bearings series and UCP UCF UCFL UCT UCFC UCPH UCPA 200 and 300 pillow block bearing series.
Specification:
1.Bore diameter: from 12mm to 140mm:
2.Outer diameter: from 47mm to 300mm:
3.Material:bearing steel/chrome steel--China,(AISI)52100--American,(Din)100Cr6--Germany
4.Certificates:ISO9001:2008/TS16949
5.Feilds Used in: Motorcycle, Motor, Pump, Fan, Air conditioner, Microwave Oven ,Sewing Machine, Massage Chairs, Agriculture Machinery, Fitness equipment, Washing Machine, Office equipment.
Insert ball bearing unit is consisted of a double sealed, single row bearing and one of housings(cast iron housing, stamping steel housing, stainless steel housing, engineering plastic housing, nodular cast iron housing, nickel plating housing, zinc alloy housing, etc). They are widely used inagricultural machinery, construction machinery, textile machinery, foodstuff machinery and conveying devices, etc.
Pillow block bearing are a form of mounted bearing used to provide load support for a rotating shaft. Selection of the appropriate bearings can be accomplished based on the shaf t size and the radial and thrust load requirements. Pillow block bearings are designed to support a shaft: the mounting surface is on a parallel line with the axis of the shaft. Elongated bolt holes in the base or feet of the unit allow for some adjustment and easy mounting of the pillow block bearing.
Product categories:
UC200 Series:UC201, UC202, UC203,UC204,UC205, UC206, UC207, UC208, UC209, UC10, UC211, UC212, UC213, UC214, UC215, UC216, UC217, UC208, UC209, UC210, UC211, UC212, UC213, UC214, UC215, UC216, UC217, UC218
UC300 Series: UC305, UC306, UC307, UC308, UC309, UC310, UC311, UC312, UC313, UC314, UC315, UC316, UC317, UC318, UC319, UC320, UC321, UC322, UC324, UC326, UC328
UCF 200 Series: UCF204,UCF205,UCF206.UCF207,UCF208,UCF209,UCF210,
UCF211, UCF212, UCF213, UCF214, UCF215, UCF216, UCF217, UCF218
UCF 300 Series:UCF305,UCF306,UCF307UCF308,UCF309,UCF310,UCF311,
UCF312,UCF313,UCF314,UCF315,UCF316,UCF317,UCF318,UCF319,
UCF320, UCF321, UCF322,UCF324, UCF326, UCF328
UCP 200 Series, UCP 300 series,UCP all series
if you are interested in our products, conact me freely.
Attn:connie
email:connie at
whatspp:+8615073676619
wechat:empty919
