Cheap FK/FF10 End Support Bearings
Description
The FK10 Series Support Unit for Ball Screws (End Support Bearings) are fabricated with high precision (C5 Class) engineered bearings. These end support ball bearings are designed so that the bearing stiffness is greater than conventional bearings. All end support bearings are pre-loaded so complicated adjustments and measurements are removed making them extremely simple to install. These end support bearings are used in linear motion actuators of high precision and speed; as well, as in precision measurement equipment.
Precision flange style ball screw support unit fixed side. Nominal ball screw sizes from 8mm to 40mm.
Application
1.Optical measuring instrument
2.Precise gauge in opitical experiment
3.Precision fine tunning optical stage
4.Mcro-hole EDM, PCB drilling machine
5.Measuring instruments
6.Operation mechanism
7.Survey device. Quantitative movement
Datasheet
| Model No. | d1 | L | H | F | E | Dg6 | A | PCD | B | L1 | T1 | X | Y | Z |
| FK 4 | 4 | 15 | 6 | 9 | 17.5 | 18 | 32 | 24 | 25 | 5.5 | 3 | 3.4 | 6.5 | 4 |
| FK 5 | 5 | 16.5 | 6 | 10.5 | 18.5 | 20 | 34 | 26 | 26 | 5.5 | 3.5 | 3.4 | 6.5 | 4 |
| FK 6 | 6 | 20 | 7 | 13 | 22 | 22 | 36 | 28 | 28 | 5.5 | 3.5 | 3.4 | 6.5 | 4 |
| FK 8 | 8 | 23 | 9 | 14 | 26 | 28 | 43 | 35 | 35 | 7 | 4 | 3.4 | 6.5 | 4 |
| FK 10 | 10 | 27 | 10 | 17 | 29.5 | 34 | 52 | 42 | 42 | 7.5 | 5 | 4.5 | 8 | 4 |
| FK 12 | 12 | 27 | 10 | 17 | 29.5 | 36 | 54 | 44 | 44 | 7.5 | 5 | 4.5 | 8 | 4 |
| FK 15 | 15 | 32 | 15 | 17 | 36 | 40 | 63 | 50 | 52 | 8 | 6 | 5.5 | 9.5 | 6 |
| FK 20 | 20 | 52 | 22 | 30 | 50 | 57 | 85 | 70 | 68 | 10 | 10 | 6.6 | 11 | 10 |
| FK 25 | 25 | 57 | 27 | 30 | 60 | 63 | 98 | 80 | 79 | 13 | 10 | 9 | 15 | 13 |
| FK 30 | 30 | 62 | 30 | 32 | 61 | 75 | 117 | 95 | 93 | 11 | 12 | 11 | 17.5 | 15 |
Company introduce
ChangshaTerry Machinery Co.,Ltd is a leading international trading company. The growing economics and convenient transportation of Changsha benefits the development of Terry Machinery.
Our products are utilized in commercial, industrial and custom application. Terry Machinery is specialized in engineering machinery bearing and vehicle industrial bearing. Our products have been exported over 46 countries.
The goal of Terry Machinery is to provide out customers with widest range of bearing at lowest price, backed with the best service.
Our service
Quick reply
We will reply your inquiry within 12 hours , phone, email and skype/ whatsapp/ wechat prompt reply.
Free samples supply
If you need samples, we can provide free samples of small quantity reassure you do business. If you need large quantity samples, you have to pay the samples charges.
After sale
For after-sales problems , we solved promptly and carefully, to make sure you satisfied.
Customized service
OEM&ODM hydraulic hose fitting available. We can make the production as customers’ drawing or samples. We provide OEM custom packaging service to customers in order to produce the strongest support
FAQ
1.What is the producing process?
Production process including raw material cutting, machine processing, grinding, accessories cleaning, assemble, cleaning, stoving, oil coating, cover pressing, testing, package.
2.How to control the products quality?
Combining advanced equipment and strict management, we provide high standard and quality bearings for our customers all over the world.
3. What is the transportation?
If small quantity , we Suggest to send by express, such as DHL,UPS, TNT FEDEX. If large amount, by shipping.
4. Can we design packaging?
Yes. Default is regular packing, and we can make customer's own packing.
5. Can you provide OEM service?
Yes, we work on OEM orders. Which means size, quantity, design, packing solution, etc will depend on your requests; and your logo will be customized on our products.
6. Could you tell me the delivery time of your goods?
3-7 days stock goods and other goods according to the quantity about 3-21 days.
7. Can you give me discount on bearing?
Yes, of course. Pls. send me your Email, you’ll get more
.
