airplane KAYDON JU065 thin section bearing
Thin Section Bearings are available open, shielded or sealed. Available in a variety of standard and custom inch and metric sizes, our thin section bearings offer high performance in corrosive and non-corrosive environments where space devoted to bearings is at a minimum.
Our Thin Section Bearing and extra thin section bearings are available in both chrome and stainless steel.
Other types bearing:
R Series - Inch dimensional series with bore sizes ranging from 3/8" to 1-5/8"
6700 Series - Metric dimensional series for very limited space applications and very light loads
6800 Series - Metric dimensional series for limited space applications and light loads
63800 Series - A hybrid between the 6800 and 6900 Series with the load capacities of the 6800 series but the width of the 6900 series.
6900 Series - Metric dimensional series for limited space applications and heavier loads
Silverthin & KAYDON Type - They are available in standard configurations, sealed and unsealed, up to 40 inches in diameter.
Application:
- Aerospace and defense
- Astronomy instrumentation
- Fixturing and workholding equipment
- Food processing equipment
- Glassworking equipment
- Index and rotary tables
- Packaging equipment
- Machine tools
- Medical systems and medical devices
| ype | d mm | D mm | B mm | Ball | Mass Kg | Co(N) | Cr(N) | |
| JU040CP0 | JSU040CP0 | 101.6 | 120.65 | 12.7 | 35 | 0.249 | 9,340 | 5,740 |
| JU042CP0 | JSU042CP0 | 107.95 | 127 | 12.7 | 37 | 0.263 | 9,880 | 5,870 |
| JU045CP0 | JSU045CP0 | 114.3 | 133.35 | 12.7 | 39 | 0.277 | 10,410 | 6,010 |
| JU047CP0 | JSU047CP0 | 120.65 | 139.7 | 12.7 | 41 | 0.295 | 10,940 | 6,090 |
| JU050CP0 | JSU050CP0 | 127 | 146.05 | 12.7 | 43 | 0.308 | 11,520 | 6,180 |
| JU055CP0 | JSU055CP0 | 139.7 | 158.75 | 12.7 | 47 | 0.336 | 12,590 | 6,410 |
| JU060CP0 | JSU060CP0 | 152.4 | 171.45 | 12.7 | 51 | 0.367 | 13,660 | 6,630 |
| JU065CP0 | JSU065CP0 | 165.1 | 184.15 | 12.7 | 55 | 0.395 | 14,720 | 6,810 |
| JU070CP0 | JSU070CP0 | 177.8 | 196.85 | 12.7 | 59 | 0.422 | 15,790 | 6,980 |
| JU075CP0 | JSU075CP0 | 190.5 | 209.55 | 12.7 | 63 | 0.449 | 16,860 | 7,120 |
| JU080CP0 | JSU080CP0 | 203.2 | 222.25 | 12.7 | 67 | 0.481 | 17,930 | 7,340 |
| JU090CP0 | JSU090CP0 | 228.6 | 247.65 | 12.7 | 75 | 0.535 | 20,060 | 7,700 |
| JU100CP0 | JSU100CP0 | 254 | 273.05 | 12.7 | 83 | 0.594 | 22,200 | 7,920 |
| JU110CP0 | JSU110CP0 | 279.4 | 298.45 | 12.7 | 91 | 0.649 | 24,330 | 8,360 |
| JU120CP0 | JSU120CP0 | 304.8 | 323.85 | 12.7 | 99 | 0.708 | 26,470 | 8,780 |
