Sell MMDS Antenna

Sell MMDS Antenna photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2004
Total Employees:
101 - 200 People
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Model No.:FYNWXC-TX
Product Origin:China
Brand Name:FEIYUE
Price Terms:
Payment Terms:
Certification:
Description:MODLE: PX-200 Input Frequency range: 2.1~2.3GHz/2.3~2.5GHz/2.5~2.7GHz Input connector: integrated dipole Gain: 38±2dB (Typ.) Gain flatness: ±0.25dB/6MHz; ±1.5dB/ in band Noise figure: 1.5dB (Typ.) IF rejection at RF port: 60dB (min.) Image rejection: 45dB (Typ.) L.O. frequency: customer's decision L.O. frequency stability: ±25kHz@-30~+60°C LO. Frequency phase noise -80dBc/Hz (@1kHz) -85dBc/Hz (@10kHz) -100dBc/Hz (@100kHz) Output frequency range: customer's decision Output power (at 1dB gain compression): 13dB (min.) Output connector: 75F type female Operating voltage: 15~24V DC D.C. current consumption: 220mA (max.) Operating temperature -40
