Hardware:

CPU

Action Micro AM8253

RAM

DDR2 64MB

ROM

Nand Flash 128MB

Wi-Fi

Realtek RTL8188 2.4Ghz IEEE802.11n 150 Mbps (b/g/n compatible)

Protocol:

DLNA, AirPlay, Qplay

Stream music to Stereo Speaker or Amplifier Receiver via Wi-Fi

Interface:

Mode (Reset)

Long press, reset to factory default

DC

DC 5V/1A via Micro USB. Connect this port to the Power adapter.

AUX

Output audio to Stereo Speaker or Amplifier Receiver via 3.5mm stereo cable.

Micro SD

Play the music directly from SD card; Share the content though Wi-Fi

Optical Audio

Output digital audio to digital speaker or amplifier

Coaxial Audio

Output digital audio to coaxial speaker or amplifier

On/Off

Power on/off device

Others Parameters

Audio Format:

MP3,AAC,WAV,FLAC,APE,OGG,WMA,DTS,AC3,m4a

Decoding

24bit/96KHZ

Frequency Response(20hz~20Khz)

-0.5db

THD+N (-6dB Input)

-85.3db

Bit Rate

1441kbps

Signal Noise Ration (SNR):

>92dB (AUX and RCA output)

WiFi configuration:

Set up in free App.

Free App for Android, iOS, Windows, Windows Phone, MAC devices

WiFi range:

30-100Meter

TCP/IP

Full TCP/IP protocol,TCP/IP bandwidth above 20Mbps

Wi-Fi protocol support

HTTP/RTSP/MMS/DMC/DMR/DMS

Encryption

WEP/WPA-PSK/WPA2-PSK

Power

5V/1A

Working Temperature:

0°C ~ +70°C

Certification

CE, EMC, R&TTE, RoHS, Wi-Fi

Accessory List

1x Micro USB Cable, 1xManual.  Optional: 1xPower Adapter, 1x3.5mm AUX cable, 1xRCA cable

Function

Bluetooth

Wi-Fi

Conclusion

Transfer Speed

1-3Mbps

150Mbps

50 times difference

Tone Quality

768kbps MP3 common tone quality

Hi-Fi level tone quality

Wi-Fi is able to stream lossless audio tone quality, but it is unable for Bluetooth

Transfer distance

<10m

100m

10 times difference

Wall Penetrability

No

Yes

Wi-Fi can be used in the whole family area, but Bluetooth works only within a room

Internet Connection

No

Yes

Wi-Fi can connect to a internet directly, and be used as a cloud speaker; Bluetooth has to be used together with other devices.

QTY of user control

1 to 1

Max 255

Wi-Fi supports multi-devices simultaneous connection, Bluetooth only supports single match.

Use Environment

No Bluetooth at home

Have Wi-Fi at home

Wi-Fi is more convenient to use.

Protocol Supported

A2DP, Lossy Transmission

DLNA, AirPlay, Qplay

Wi-Fi adopted Lossless Transmission Protocol, Microsoft, Apple and Tencent all have launched related applications.
