GC-101H High Sensitivity Hand-held Metal Detectors

GC-101H high sensitivity hand-held metal detectors

GC-101H ultra-sensitive multi-functional hand-held metal detectors, it is a high-performance designed specifically for the security metal detectors. Compared with traditional detectors, GC-101H type ABS plastic shell with a cast, use face detection area specially designed, more technologically advanced sound and light alarm and vibration alarm devices, higher sensitivity, more accurate alarm , more power, longer working hours, in similar products apart is its unparalleled flow line design. The product uses a large-scale CMOS integrated circuits, electronic buzzer, ferromagnetic, metal and other objects have detection. Good looks, compact, easy to use, ability to fight, is ideal for checking illegal goods rare.

Applications:
Airports, railway stations, customs, wharf, stadium (gymnasium), border control, defense department security checks, precious metals testing (such as gold and silver jewelry factory, electronic components factory) and security sites to be detected.

Features
1. streamline design, elegant, high sensitivity.
2. light weight, large area detection sensor to detect speed.
3. Two alarm modes are available: LED light audible alarm or vibrating alarm.
4. rugged, free-fall height of one meter without damage.
5. voltage indicator / charge indicator timely reminder.
6. After installation of the rechargeable battery, can be used directly for this product is fully charged.

Detection range
This detector sensor sensitivity is to detect metal objects because of the volume, size and density of the surrounding environment
Factor varies. Factory Standard:
Pin 30-60 mm
One yuan coin 75-100 mm
Six inches Tool 160-10mm
20MM Ball 180-195mm

1. Alarm Indication
Steady Yellow LED: Target has been detected
Flashing green LED: Power
Flashing red LED: Low Voltage Directive
2. Alarm signal
Sound mode Buzzer and red LED
Vibration mode and the red LED
3. Battery
A 9V alkaline or lithium batteries
30-40 hours of battery life (lithium battery)
28 hours (alkaline batteries)
4. Temperature: -15 to 45 degrees Celsius
5. Frequency: 25 Hz
6. Reset time: 0.5 seconds, automatic
7. Size
Weight: 225 grams (without batteries), width: 77 mm, height: 26 mm, length: 375 mm
