Specifications
7" TFT LCD Display Color 2 Video Input Car RearView Headrest Monitor DVD VCR Monitor + Car Rear View Parking Camera KitSpecifications:
7 inch TFT Color LCD Car Rear View Camera Monitor
Display Screen:
- Screen Size: 7 inch
- Display Component: Color TFT LCD
- Screen ratio 16:9/4:3 adjustable
- Resolution: 480 x 234 Pixels
- Contrast Ratio: 100:1
Housing Material: ABS
Video Frequency: PAL/NTSC
Main function:
- 100% Brand New, with 7 inch LED backlight color TFT LCD display monitor.
- With 2 AV input. AV1 connects to car DVD, VCR and other video equipment. AV2 to car backup camera.
- Parking rear view priority: The monitor will start up automatically, and synchronously display the video from rear view camera when you're backing your car; the monitor will close itself after backing.
- Scenes will cut to rear view camera automatically while you're backing the car and change back to the original scene after that.
- Blue wire is for displaying car reversing image automatically when it's connected with a rearview camera.You need to adjust it manually if the blue wire is not connected.
- Support rotating the screen
- Support adjust the Brightness, contrast, color.
- 2 ways to install: standing or mounting.
- Low power consumption.
- No Audio input or output.
- Comes with an IR remote controller for a easy operation.
- Working perfectly with Car DVD, VCD, camera, STB, satellite receiver, and other video equipment.
Power supply: DC 12V
Working Temperature:
- Work: 0 to 80 degrees C
- Storage: -10 to 80 degrees C
E306 18mm Color CMOS / CCD Outside & Water-Resistant Car Camera
TV System: PAL / NTSC
Effective Pixel: 628 * 586 / 828 * 686
Sync System: Internal
Scanning System: 2 : 1 Interlace
Resolution: 420 TV lines
Lens Angle: 2.8mm / 120 degrees - 1.8mm / 170 degrees
Sensor Area: 5.961mm x 4.276mm
Video Output: 1.0Vp-p, 75Ohm
S / N Ratio: More than 48 db
Water-proof: IP67 - IP68
Current Consumption: No more 300mA
Power Supply: DC 12V
Operating Temperature: -20 ~ 60 degrees(RH95%Max.)
Storage Temperature: -20 ~ 60 degrees(RH95%Max.)
Other Items: Automatic white balance, Agc and BLC
Package Weight: 840g
Approved: CE / FCC
After Sales Service: 1 Year Warranty
Accessories:
Car Monitor
1 x Bracket
1 x Video & Power Cable
1 x Remote Controller
1 x User Manual
Car Camera
1 x Video Cable
1 x Power Cable
