Side mounted Waterwork construction stanchion
1. Surface Treatment G: G means hot-dip galvanizing, other surface treatment is not marked.
2. Quantity of horizontal pole:
A.one horizontal pole; B. two horizontal poles; C. three horizontal poles.
3. Types of Vertical Railing include P, C, W, S, SC, SO, MB (Multi ball).
4. Types of Inclined Railing include PA, CA, WA, SAL, SAR, AM, SOAL, SOAR.
5. Quantity of the post (pillar): A. one post; B. two posts(pillar)
6. Specification: S means standard type; E means economical type.
7. Materials: C = carbon steel; S=stainless steel
8. Rail height: single rail manufactured according to design, double rail is 1.1m, and triple rail is 1.2m.
9. Column spacing: mainly four kinds as 1000mm, 1200mm, 1500mm, 2000mm.
| Style | Ball diameter | Column pipe diameter | Handrails diameter | Knee rail pipe diameter |
| standard | 76mm (85) | 48.0mm (51) | 42.3mm (51) | 33.5mm (38.2) |
| economy | 66mm (70) | 42.3mm (38.1) | 33.5mm (38.1) | 26.8mm (32) |
