Rosemount 5400 Non-Contacting Radar Level Transmitter

Rosemount 5400 Non-Contacting Radar Level Transmitter

Introduction

The Rosemount 5400 Level Transmitter provides accurate level measurements of liquids, slurries, and solid materials. The non-contacting measurement technology with no moving parts requires minimum maintenance. It measures the level top down and is therefore unaffected by most fluid property changes, like density and viscosity. The Rosemount 5400 is designed to overcome the challenges of obtaining reliable solids measurements. Its unique algorithm provides reliable measurement on solid materials in challenging conditions such as angled or uneven surfaces, multiple surface echoes, and on products with a low dielectric constant.

Specifications

Accuracy

5401：±10mm

5402：±3mm

Operating Pressure

Full vacuum to 232 psi (Full vacuum to 16 bar)

Operating Temperature

-40 to 302°F (-40 to 150°C), -67 to 392°F (-55 to 200°C) for parabolic antenna

Communication Protocol

4-20 mA/HART®, Foundation™ Fieldbus, Modbus®

Safety

TÜV tested and WHG approved for overfill prevention

Antenna Type

Cone antenna, Rod antenna, Process seal antenna, Parabolic antenna

Operating Frequency

Low or high frequency options (6 GHz or 26 GHz)

Warranty

Up to five years

Features

·  Air purging connection prevents clogging of the antenna in extremely dusty environments and applications prone to product build-up

·  Dual Port Technology provides optimal signal strength and sensitivity

·  Signal Quality Metrics detects and monitors abnormal process conditions such as antenna coating or foam

·  Solid measurement with unique solids algorithm

Common models

5402AH1E54SPVCA - M1C1

5402SH1E54SPVCA - M1 C1

5402AF1E54SPVCA - M1C1

5402AF1E54SPVCA - M1C1

5402AF1E54SPVCA - M1C1

5402AF1E54SPVCA - M1C1

5402AM1E54SPVCA - M1C1

5402AM1E54SPVCA - M1C1

5402AM1E54SPVCA - M1C1

5402AM1E54SPVCA - M1C1

5402AU1E54SPVCA - M1C1

5402AU1E54SPVCA - M1C1

5402AU1E54SPVCA - M1C1

5402AU1E54SPVCA - M1C1

5402AH2E54SPVCA - M1C1

5402SH2E54SPVCA - M1 C1

5402AF2E54SPVCA - M1C1

5402AF2E54SPVCA - M1C1

5402AF2E54SPVCA - M1C1

5402AF2E54SPVCA - M1C1

5402AM2E54SPVCA - M1C1

5402AM2E54SPVCA - M1C1

5402AM2E54SPVCA - M1C1

5402AM2E54SPVCA - M1C1

5402AU2E54SPVCA - M1C1

5402AU2E54SPVCA - M1C1

5402AU2E54SPVCA - M1C1

5402AU2E54SPVCA - M1C1

5401AH1NA4SPVCA - M1C1

5401SH1NA4SPVCA - M1C1

5401AF1NA4SPVCA - M1C1

5401SF1NA4SPVCA - M1C1

5401AH2NA4SPVCA - M1C1

5401SH2NA4SPVCA - M1C1

5401AF2NA4SPVCA - M1C1

5401SF2NA4SPVCA - M1C1

5401AH1E14SPVCA - M1C1

5401SH1E14SPVCA - M1C1

5401AF1E14SPVCA - M1C1

5401SF1E14SPVCA - M1C1

5401AH2E14SPVCA - M1C1

5401SH2E14SPVCA - M1C1

5401AF2E14SPVCA - M1C1

5401SF2E14SPVCA - M1C1

5401AH1I14SPVCA - M1C1

5401SH1I14SPVCA - M1C1

5401AF1I14SPVCA - M1C1

5401SF1I14SPVCA - M1C1

5401AH2I14SPVCA - M1C1

5401SH2I14SPVCA - M1C1

5401AF2I14SPVCA - M1C1

5401SF2I14SPVCA - M1C1

5401AH1E54SPVCA - M1C1

5401SH1E54SPVCA - M1C1

5401AF1E54SPVCA - M1C1

5401SF1E54SPVCA - M1C1

5401AH2E54SPVCA - M1C1

5401SH2E54SPVCA - M1C1

5401AF2E54SPVCA - M1C1

5401SF2E54SPVCA - M1C1

5401AH1I54SPVCA - M1C1

5401SH1I54SPVCA - M1C1

5401AF1I54SPVCA - M1C1

5401SF1I54SPVCA - M1C1

5401AH2I54SPVCA - M1C1

5401SH2I54SPVCA - M1C1

5401AF2I54SPVCA - M1C1

5401SF2I54SPVCA - M1C1
