GDE-1B Engler Viscometer

GDE-1B Engler Viscometer thumbnail-1
GDE-1B Engler Viscometer photo-1
US$ 1 - 1 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
GOLD
Place of Origin:
China
Model Number:
GDE-1B
Contact Supplier Request Quote Chat Now
Chongqing Gold Mech
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOLD
Place of Origin China
Model Number GDE-1B

Introduction:

1. This instrument is designed and made as per national standard GB/T266 Petroleum Products- Determination of Engler Viscosity, T0622 Bitumen Engler Viscosity Determination(Engler viscometer method) in national industrial standard JTG E20-2011 Standard Test Methods of Bitumen and Bituminous Mixtures for Highway Engineering and Shanghai enterprise standard Q/YXYY11 WNE-1 Engler Viscometer.

2. It is suitable to determine the rate of time(seconds) of liquid flow out from Engler viscometer and time(seconds) of distilled water flow out at 20℃ under certain temperature and cubage. This rate is the Engler viscosity. Unit is Engler degree.


I. Main technical features:

1. The instrument adopts desktop, all-in-one and double inner crucible structure. Both of inner and outer crucibles adopt stainless materials. Inner crucible has been specially pr℃essed. The smooth finish corresponds with the test requirements.

2. The flow out time adopts digital display. Can do parallel determination for 2 samples at the same time. Easy to use and efficiency is high.

3.The temperature controller adopts digital display temperature controller with P,I,D position regulatory function. Easy to set the parameters and temperature controlling precision is high.


II. Main technical specifications:

Power supplyAC（220±10%）V, 50Hz
Standard water value(51±1)s
Temperature range(0～100)℃
Temperature control accuracy±0.1℃
Engler viscosity thermometerCorrespond with GB/T 514
Specification of measuring flask(200±0.2) ml
Inner crucibleStainless steel material
Timing Max 999.9s
Timing modeLED electronic timing
Heating power700W
Ambient temperature(-10～+40)℃
Relative humidity ≤85%
Dimension430mm×410mm×620mm
Maximum power consumption800W


Product Tags: Engler viscosimeter , Engler viscosity tester , Asphalt material stability tester
