Detailed Product Description
| Sheath Material: | PVC | Range Of Application: | Factory Device |
| Type: | Insulated | Conductor Material: | Copper |
| Conductor Type: | Solid | Material Shape: | Twisted Pair |
| Cable Length: | 6.5meters | Color: | Black / OEM |
| Connection: | Over Mold |
RJ45 to Hirose 8pin HR25 - 7TP - 8S SSTP Double Shielded Gigabit Ethernet Cables for Sony Camera
Description:
Sony camera network cables
Customized ethernet cable assemblies with Hirose HR25 Circular Connector and RJ45 connector
Connector A: original Hirose 8 pole / 8 pin HR25 - 7TP - 8S /HR25-7TP-8P Straight or right angle
Connector B: RJ45 straight or right angle,with screw fasten or no screws
Cables: SSTP double shielded Gigabit Ethernet cables CAT6
Specification:
High Performance Cat6a, 26 AWG, RJ45, Shielded Ethernet Cable provides universal connectivity for LAN network components such as gige vision cameras, host computers,PCs, computer servers, printers, routers, switch boxes, network media players, NAS, VoIP phones, PoE devices, and more
Cat6a performance at a Cat 5e price but with higher bandwidth; SSTP/SFTP (Screened Foiled Twisted Pair) shielding can prevent electromagnetic interference (EMI) and reduce crosstalk noise
A Category 6a Ethernet patch cable is also referred to as a Cat6a network cable, Cat6a cable, Cat6a Ethernet cable, or Cat 6a data/LAN cable. Future-proof your network for 10-Gigabit Ethernet (backwards compatible with any existing Fast Ethernet and Gigabit Ethernet); Meets or exceeds Category 6a performance in compliance with the TIA/EIA 568-C.2 standard
The shielded connectors with gold-plated contacts, molded strain-relief boots, and snagless molds resist corrosion, provide durability, and ensure a secure connection; Bare copper conductors enhance cable performance and comply with specifications for communications cables
Flexible and durable Cat6a cable with high bandwidth of up to 550 MHz guarantees high-speed data transfer for server applications, cloud computing, video surveillance, and online high-definition video streaming
Features:
Cost Saving Adapters for industrial cameras
8 Pin hirose HR25 - 7TP - 8S /HR25-7TP-8P Connector to RJ45
Full shieded cables No Signal Loss
Assembly in China,materiel from Taiwan, USA, Germany,Japan,made with Quality Components
RJ45 Connectors and hirose connector molding type
Hirose Connectors: we have alternative hirose connector 6pin hr10-10p-6s hr10-10p-6p , 12pin hr10-10p-12s hr10-10p-12p ,8pin HR25 - 7TP - 8S /HR25-7TP-8P,right angle orientation and straight orientation molding type.
1 Year Warranty
CAT 6,Cat 5e available
Transmission of high-speed
Full shielded
Overmolded
Mostly shipped to Germany,Italy,Netherland,Newzealan,USA,Korea etc..
Quality is good,100%tested before shipping
-
Product Certifications:
Certificate Standard: UL
View scanned certificationCertificate Number: E348437 Issue Date: 15-Jul-2011 Issued By: Expiry Date: 15-Jul-2015 Scope/Range: All cables Certificate Standard: CE
View scanned certificationCertificate Number: A001P100531006E Issue Date: 03-Jun-2010 Issued By: Expiry Date: 03-Jun-2015 Scope/Range: All Cables Certificate Standard: FCC
View scanned certificationCertificate Number: A001P100531007E Issue Date: 04-Jun-2010 Issued By: Expiry Date: 04-Jun-2015 Scope/Range: All Cables Certificate Standard: SGS Certificate Number: GZ1006059885 Issue Date: 08-Jun-2010 Issued By: Expiry Date: 08-Jun-2015 Scope/Range: All Cables
