This potting is a two-component silicone sealing material，which can be cured at room temperature.The ethanol molecules are released during the curing process,and it does not produce corrosion to Poly-carbonate PP, ABS, PVC, copper and so on.It has a good adhesion for most of the electronic accessories (PP, PE excluded).
Performance | Reference standard | TS3366 | |
Before curing
| Appearance | Visual | black（A）/（B）black fluid |
Viscosity of part A （cps，25℃） | GB/T 2794-1995 | 1500-1800 | |
Viscosity of part B （cps，25℃） | GB/T 2794-1995 | 5-10 | |
Operation | Mix ratio | Measured by system | A ：B = 10 ：1 |
Density（g/cm3） | GB/T 533-2008 | 1.122 | |
Viscosity （cps） | GB/T 2794-1995 | 1000-1200 | |
Operable time （min，25℃） | Measured in the environment | 15-25 | |
Tack-free time （min，25℃） | GB/T 13477.5-2002 | 30-45 | |
Curing time （h，25℃） | Measured in the environment | 24 | |
After curing | Hardness(shore A) | GB/T 531.1-2008 | 10～15 |
Thermal Conductivity [ W（m·K）] | ASTM D5470-06 | 0.3 | |
Break voltage（kV/mm） | GB/T 1695-2005 | ≥20 | |
Dielectric constant（1.2MHz） | GB/T 1693-2007 | 2.5 | |
Volume resistivity （Ω·cm） | GB/T 1692-2008 | 5×1014 | |
TEMP(℃) | Measured in the environment | -50～200 | |
Elongation（%） | GB/T 528-2009 | 200 | |
Tensile strength（MPa） | GB/T 528-2009 | 0.4 | |
Apply to potting protection of both indoor and outdoor LED full color display and electronic components module potting.
Advantages
1.Low viscosity, good leveling, light weight.
2.There is no corrosion to LED product since the product belongs to the dealcoholization reaction.
3.Excellent heat resistance, moisture resistance and cold resistance,it can extend the life of electronic accessories after applying.
4.It is removable,the sealed components can be replaced and without leaving traces when re-irrigate and repair.
5.This product does not need other primers,it has excellent adhesion to PC (Polycarbonate), epoxy and other materials ,the waterproof rating is up to IP65.
6.Fully cured material has a good insulation,damp-proof,mildew proof chemical-resistance,UV resistance and aging-resistance.besides,it can fit extreme temperature that can work stable for a long time under -50-200℃.
7.Fully in line with the ROHS directive requirements in EU.
