46inch DID Full hd Panel Ultra Narrow Bezel 3x3 Lcd Video Wall(HQ460-V,support Touch and Pc)
US$ 499 - 9,999
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Chimee
Model Number:
HQ460-V
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
46inch 5.3 mm Ultra Narrow Bezel Exhibition Lcd Video Wall(HQ460-V,support Touch and Pc)NegotiableMOQ: 1 Unit -
46inch Full Color Backlit Led DID Lcd Screen Indoor Video Wall (HQ460-V,2X2 Models,5.3mm or 6.7mm)US$ 1,500 - 10,000MOQ: 1 Set
-
46inch New Lcd Background Video Wall(HQ460-V,2X2 Models,5.3mm or 6.7mm)US$ 1,500 - 10,000MOQ: 1 Set
-
46inch Interactive Hdmi Video Wall Controller(HQ460-V,2X2 Models,5.3mm or 6.7mm)US$ 1,500 - 10,000MOQ: 1 Set
-
46inch Lcd Ultra Narrow Bezel Exhibition Video Wall (HQ460-V,2X2 Models,5.3mm or 6.7mm)US$ 1,500 - 10,000MOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
Chimee
Model Number
HQ460-V
Type
Other, DID Screen
Application
Indoor
Panel Size
46 jnch
Max Resolution
1920 x 1080
Viewing Angle
178°/178°(H/V)
Pixel Pitch
0.4845(H)*0.4845 (V)
Color
16.7M
Contrast Ratio
4000:1
Brightness
450cd/m2
Response Time
6ms
Input Voltage
AC100~240V 50 /60 HZ, AC110V-240V, 50/60HZ
Buying Guides
Product Model:
HQ460-V
46inch DID full hd panel ultra narrow bezel 3x3 lcd video wall(HQ460-V,support touch and pc)
Product Pictures:
Panel Specifications:
| Specifications | |
| Model No. | HQ460-V |
| Panel Size | 46'' Samsung DID LCD Screen(narrow bezel 5.3mm) |
| Aspect Ratio | 16:9 |
| Max Resolution Support | 1920*1080 |
| Color | 8Bit,16.7M |
| Brightness (nits) | 700cd/m2,500cd/m2 |
| Contrast | 4000:1 |
| Visual Angle (H/V) | 178 |
| Response Time | <=6ms |
| Life(hrs) | >60,000(hrs) |
| Video Wall Processor Secifications | |
| Input | CVBS | 3*BNC inputs, support PAL/NTSC, 2*BNC loop outputs | ||||||||||||||
| VGA | 1* D15 port, support SVGA/XGA/WXGA | |||||||||||||||
| YPbPr | 1* YPbPr Input, Support PAL/NTSC | |||||||||||||||
| Y/C | 2* BNC inputs, support PAL/NTSC | |||||||||||||||
| Output | LVDS | Support single or double LVDS output, and WUXGA(1920*1080) | ||||||||||||||
| Operate Mode | Panel key operation (Need customization) | |||||||||||||||
| Infrared Remote Control Operation | ||||||||||||||||
| Standard RS232 port (provide free control software) | ||||||||||||||||
| Engineering Software | Customized | |||||||||||||||
| Temperature | -20°C ~ 50°C | |||||||||||||||
| Humidity | 5% ~ 95% | |||||||||||||||
| Power Supply | AC 110V ~ 240V, 50/60Hz | |||||||||||||||
| Power Consumption | Max 300W, according to different screen models | |||||||||||||||
| Processor Size | 307×282×53.8 (mm) | |||||||||||||||
| Weight | 19Kg to 45Kg | |||||||||||||||
Product Features:
1.Narrow bezel design ---Industrial grade LCD panel ,high quality ,Practical ,good vision effect.
2.Signal interface rich --- RS232, HDMI,DVI,VGA,Y Pb Pr ,AV
3.HD video wall unit--- High brightness,high contrast,High gamut .
4.Flexible structure design ---easy installation ,extensible,arbitrary combination
5.table performance,suitable working for a long time
Product Functions:
Video wall Project:
Video Wall Application :
Product Package:
Product Certification:
A/S Terms:
1. Online technical support with Skype, Yahoo messenger, MSN, Teamview etc.
2. Free spare parts shipping, after checking by pictures and videos, if we confirm the damage not cause by human, we will ship spare parts to do the replacement for free.
3.Online support and sending user manual for buyer's technician to do the replacement of the damage parts.
♥ If you want to know more about our products and company, welcome to contact us at any time. ♥
Hot-line: 0086-15818572697
Skype ID: lizchimee
Chimee has own factory,can also support OEM and Customization sevice.
