80% ZrO2 Cerium Stabilized Zirconia Beads

80% ZrO2 Cerium Stabilized Zirconia Beads thumbnail-1
80% ZrO2 Cerium Stabilized Zirconia Beads thumbnail-2
80% ZrO2 Cerium Stabilized Zirconia Beads thumbnail-3
80% ZrO2 Cerium Stabilized Zirconia Beads thumbnail-4
80% ZrO2 Cerium Stabilized Zirconia Beads thumbnail-5
80% ZrO2 Cerium Stabilized Zirconia Beads photo-1
80% ZrO2 Cerium Stabilized Zirconia Beads photo-2
80% ZrO2 Cerium Stabilized Zirconia Beads photo-3
80% ZrO2 Cerium Stabilized Zirconia Beads photo-4
80% ZrO2 Cerium Stabilized Zirconia Beads photo-5
US$ 15 - 28 MOQ: 25 Kilograms
Key Specifications
Get Latest Price
Brand Name:
win-ceramic
Place of Origin:
China
Type:
Ceramic Balls
Contact Supplier Request Quote Chat Now
Zibo Win-Ceramic Material Co., Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao,shanghai
Delivery Detail:
3 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name win-ceramic
Place of Origin China
Type Ceramic Balls
Application Industrial Ceramic
Material Zirconia Ceramic

Application:

It is with the earth rare element “cerium”, so cerium stabilized zirconia bead has the biggest specific gravity in all zirconia beads series and it is very suitable for some special industries and grinding materials.

Especially for milling and dispersing high viscosity pastes and high purity products.



(1).Wear-resistant, corrosion-resistant products: paints, textiles, paints, printing and dyeing;

(2). High strength, high toughness products: magnetic materials, piezoelectric ceramics, dielectric ceramics ;

(3).To prevent pollution: medicine, food, cosmetics ;

(4).Ceramics: Electronic ceramics, refractory ceramics, structural ceramics.



Products Dimension

Ball

ø 0.4-0.6mm

ø 0.6-0.8mm

ø 0.6-0.8mm

ø 0.8-1.0mm

ø 1.0-1.2mm

ø 1.2-1.4mm

ø 1.4-1.6mm

ø 1.6-1.8mm

ø 1.8-2.0mm

ø 2.0-2.2mm

ø 2.2-2.4mm

ø 2.4-2.6mm

2.6-2.8mm

2.8-3.0mm







Composition

Wt%

20% CeO2 + 80% ZrO2

Specific Density

g/cm3

6.0

Color

—

Yellow/Gold

Bulk Density

g/cm33.85

Hardness

Mohs

9

Elastic Modulus

GPA

200

Thermal Conductivity

W/m.K

3

Crushing Load

KN

≥2000(ø2mm)

Fracture Toughness

Mpam1-2

8.5

Thermal Expansion Coefficient



10*10-6/℃(20-400)

 9.0
Wear Loss

ppm/hr



<10ppm/hr(24h)

Grain Size

μm



≤0.5



Features:

It has a gem-like hardness and density.Micro-structure of delicate, uniform, dense ceramics of the Quartet. Its excellent wear resistance and fracture toughness is particularly suited for grinding and dispersing high-solid-phase high-viscosity, high hardness of the paste.

(1).Long working life: 30 times longer life than glass beads, 6 times than zirconium silicate beads.

(2)High grindingefficiency: around 6 times than glass beads; 2 times than zirconium silicate bead

(3).Excellent wear resistance and fracture toughness.

Product Tags: 80% ZrO2 , cerium stabilized zirconia beads , cerium beads
