LED Gas Price Display

Specifications

LED Gas Price Panel / LED Price Display Sign

Brief Introductions:
GOOD for Pricing Displays;
The Pricing Panel is composed of separate unit of digit "8" and the digit "8" is composed of high brightness of LEDs.;
They are controlled by the Control System (this System can control 16PCS of digits "8. " in max. );
Single-side / Double-side / Three-side / Four-side can be available;
The pricing can be changed and updated by RF Remote Control and the Max. RF remote distance would be up to 100 meters;
High brightness intensity can be over 4000CD/m2 and the view angle is 120 deg. @ the big Viewing Angle (Horizontal / Vertical)
Displays: " 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, radix point "
Digit height types available: 20" or 12.5" or 8"

Notes:
1). As the above system, it needs only one AC220V to DC5V 30W to power the Control Card ( Display_Control ) & all the IC in each Digit Board;

2). Each 8PCS of Digit Boards can be powered by 1PC of AC220V to DC12V 200W OR 1PC of DC18V 200W. ( DC12V for Red LEDs while DC18V for Green / Blue / White LEDs. )

3). Therefore, the Control Card will be connected and powered by DC5V only; Each Digit Board "8" will be connected and powered by DC5V ( 1 line) & DC12V (R, 1 line) or DC18V ( G / B / W, 1 line ) & GND ( 1 line ).
