Paper Cupes Laser Engavring and Cutting Machine With High Speed MC 1290
- Any port in china
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Mini Glass Bottle Laser Engarving Machine MC9060
-
Visual CNC CO2 Water Mark Paper Laser Cutting Machine MC9060
-
Visual CNC CO2 Water Mark Paper Laser Cutting Machine MC 1290
-
Wooden Toys Laser Cutting Engarving Machine MC9060
-
Hot Sale Cnc Co2 Laser Cutter and Engarver for Sale MC9060
-
Paper Plastic Plates CO2 CNC Laser Cutting Engarving Machine MC9060
Product Details
| Condition | New | Laser Type | CO2 | |
| Engraving Area | 1200mm*900mm | Engraving Speed | 0-40000mm/min | |
| CNC or Not | Yes | Cooling Mode | Water Cooling | |
| Applicable Material | Acrylic, Crytal, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood | Graphic Format Supported | AI, BMP, DST, DWG, DXF, DXP, LAS, PLT | |
| Brand Name | MC | Model Number | MC1290 | |
| Dimension(L*W*H) | 1600*1200*1100 | Certification | CCC, CE, GS, ISO, SGS, UL | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Paper cupes laser engavring and cutting machine with high speed MC 1290
Foam board laser cutter
1 Paper cupes engavring and cutting machine details:
More specialize in manufacturing and exporting laser machine and cnc router for 7years. We can offer various of laser cutting &engraving machines for both metal and non metal materials.
1,Laser tube: With longer lifetime and longer warranty. Very stale during working.
2,Step&motor: High precision 3-phase Stepper Motor and Driver, Famous Brand with good quality.
3, HIWIN guide rail: High quality HIWIN guide rail make run faster.
4,Up&down system: According to your demand, It can help you cut&engraving different thickness materials.
5, Blade workable: According to your materials,blade table suitable for hard materials like: acrylic,wood, MDF...
Honeycomb table for soft materials like: paper,fabric,textile...
6,Control system: Adopt the famous brand, input power into CO2 laser tube to drive CO2 laser instrument, The CO2 laser tube length can be choosen from 800mm to 2000mm.
Other optional parts
1.)Up &down worktable( adjust the height of table to make worktable moves up and down automatically)
2.)Rotary attachment.( engrave cylinders,such as basketball,bottles and so on)
3.)Red dot position (make the laser beam visible)
4.)USB port ( make the machine work without a computer)
5.)Auto focus(engrave uneven surface)
2.co2 cnc laser cutting machine
Model | MC1325 | MC1625 | Option |
Working Area | 1300*2500 | 1600*2500mm | According to Demands |
Laser Power | 40w/50w/60w/80w/100w/130w//150w | ||
Laser Type | CO2 Sealed Laser Tube , 10.6μm | ||
Cooling Type | Water Cooling | ||
Engraving Speed | 0-60000mm/min | ||
Cutting Speed | 0-36000mm/min | ||
Laser Output Control | 0-100% Set by Software | ||
Min. Engraving Size | Chinese: 2.0mm*2.0mm, English Letter:1.0mm*1.0mm | ||
Highest Scanning Precision | 2500DPI | ||
Locating Accuracy | ≤+0.01mm | ||
Controlling Software | DSP Control System | ||
Graphic Format Supported | DST PLT BMP DXF DWG AI LAS,etc | ||
Compatible Software | CORELDRAW,PHOTOSHOP, AUTOCAD,TAJIMA,etc. | ||
Color Separation | Yes | ||
Drive System | High-precision 3-phase Stepper Motor | ||
Auxiliary Equipments | Exhaust Fan and Air Exhaust Pipe | ||
Power Supply | AC110V/220V+10%,50HZ/60HZ | ||
Working Environment | Temperature:0-45C,Humidity 5-95%(No Condensate Water) | ||
Option | Water chiller Red Dot Position System | ||
advantages:.
1) Our three unique protection functions, i.e. anti-interference function, water-protective function and power cut-off function ensure longer working life, safety and effectiveness.
2) Exhausting, absorbing and assistant blowing systems solve the problem that troubles the laser equipments
manufacturing industry for years, extending the life of the laser tube.
3) This machine uses USB port to transmit data, equipped with large capacity internal memory, improving working speed and efficiency greatly.
3.Technical Parameter of Paper cupes engavring and cutting machine
Model | MC1290 | Option |
Working area | 1200*900 mm | According to demands |
Laser power | 40w/50w/60w/80w/100w/130w/150w/180w for option | |
Laser type | CO2 Sealed laser tube , 10.6μm | |
Cooling type | Water cooling | |
Engraving speed | 0-60000mm/min | |
Cutting speed | 0-40000mm/min | |
Laser output control | 0-100% set by software | |
Min. engraving size | English letter:1.0mm*1.0mm | |
Highest scanning precision | 4000DPI | |
Locating accuracy | ≤+0.01mm | |
Controlling software: | DSP control system | |
Graphic format supported | DST PLT BMP DXF DWG AI LAS,etc | |
Compatible software | CORELDRAW,PHOTOSHOP, AUTOCAD,TAJIMA,etc. | |
Drive system | High-precision 3-phase stepper motor | |
Auxiliary equipment | Exhaust fan, air exhaust pipe/water pump/water chiller | |
Power supply | AC110V/220V+10%,50HZ/60HZ | |
Working environment | Temperature:0-45℃,Humidity 5-95%(No condensate water) | |
Option configuration | up&down table, honeycomb worktable,rotary device , red dot position system,auto-focus device | |
4. The samples of Paper cupes engavring and cutting machine
5,Our team:
6.Quality text :
6.Our service :
1. 24 months for machine,and 8 months for laser tube long life span of laser tube:1500-3000 hours.
2. 24 hours technical support by e-mail, calling or door-to-door service
3 .English software, user manual and detailed Videos CD
4.International quality certificate:CE,FDA,SGS,ISO9001:2008
5. professional laser machine supplier with 10 years experiences in China
6.We offer training in our factory.Welcome to our factory . Sample provided
7.Packaging and Shipping :
Every machine is packed with great care and tough material. It is packed with cling films first and then film bags. At last, it is packed with wooden case which is reinforced with the iron bar on the top and bottom With this kind machine, all our laser machine can protect well during long trip by sea or by train. We can transport machine by boat or by training, according to your requirement.
Our company :
Jinan Maidun CNC Equipment Co., Ltd. is well-known manufacturer of Laser machines in China, located in Jinan city that is famous for its fountains. We continually devote to developing, manufacturing and selling of laser engraving machine, laser cutting machine, cloth laser cutting machine, laser marking machine, Advertising laser engraving machine, woodworking laser machine, stone laser machine, glass laser machine, etc.
