10,000hours working life RECI laser tube 80w
After-sale service
1. Within 180 days from exit work date, if the user operates same as our manual and the output
power is less than 80% of the rated power, we will provide new one instead of the defected one.
The replaced laser tube has same new laser tube warranty. The single transportation freight will be afforded by buyer. When the laser tube structure is damaged changed, we will not be responsible.
2. From 180 days to 300 days, if the user operates same as our manual and the output power is
less than 60% of the rated power, we will repair or provide new one instead of the defected one
according to fact. The single transportation freight will be afforded by buyer. When the laser tube structure is damaged changed, we will not be responsible.
The replaced laser tube warranty is 90 days.
Key Notes
Do not clean the exterior surface of the output widow mirror with tools such as tampon;
otherwise the output power will be seriously affected. The followings are the designated
methods to clean up pollution in the exterior surface of window mirror:
1) When the mirror is polluted, do not turn on the laser.
2) Blow the mirror surface sideways with an air blower.
3) Spray the pure alcohol on the mirror surface with sprayer.
4) Turn on the laser after the alcohol gets fully volatilized.
5) If the methods above don't work effectively, it is necessary to ask for the professional to
use tampon with alcohol to clean the mirror surface from middle to edge. The best solution is
to prevent the window from being polluted.
Attention: it is forbidden to clean the mirror with acetone.
The screws in the front and back ends of the laser tube are not allowed to be moved,
otherwise the out power will be declined, even the tube will be scrapped.
Put the acryl 300mm far away from output mirror, when testing its laser spot.
Cardboard Carton Package Size
DESCRIPBTION |
N.W. |
G.W. |
PACKAGE/UNIT |
C.W. |
CBM |
Laser Tube S2 (90W) |
3.5KG |
5KG |
1360*250*260 mm |
18KG |
0.088 |
Laser Tube S4 (100W) |
4KG |
7KG |
1550*340*350mm |
36.9KG |
0.184 |
Laser Tube S6 (130W) |
5KG |
8KG |
1800*340*350 mm |
43 KG |
0.214 |
Laser Tube S8 (150W) |
6KG |
11KG |
2010*380*400 |
62.4 KG |
0.304 |
