Styrofoam machining center
1.1 Industry:
Styrofoam mold,wood mold,large plastic molds,large casting mold,mold shade,landscape dies mold,and other major figures.
1.2 Materials:
Styrofoam,wood,resin,aluminum,non-metallic materials,etc.
Machine Model | XJ-1325 |
Platform size | 1600x3100mm |
Working range | 1300x2500mm |
Z-axis range | 550mm |
Max Height of material | 750mm |
Machine Structure | 8mm thick heavy-duty tubular steel frame,full-welded,VSR |
Surface material | Thickend aluminum |
Fixturing method | T-slot for clamp fixture |
X,Y Transmission | Germany Slanting rack |
Z-axis Transmission | HIWIN 25 Ball Screw |
Rail configuration | HIWIN 25 Square guide rail |
Positioning accuracy | ±0.1/300mm |
Spindle speed | 0-24000(r/min) |
Y-axis dual drive | Stepper Motor LeiSai 110,Shenzhen |
X,Z axis drive | Stepper Motor LeiSai 110,Shenzhen |
Control System | NcStudion Control System of Shanghai |
Code Formats | G code,U00,mmg, nc |
Idle speed | 0-20000mm/Minute |
Working speed | 0-15000mm/Minuter |
Resolution | 0.00625/Minute |
Tool diameter | 3.175mm,4mm,6mm,8mm,10mm,12.7mm |
Spindle power | 4.5kw |
Cooling System | Water cooling |
Weight | 3100KGS |
Power | 380V50HZ±10(Internal Power) |
Electric Box | Intergrated computer control cabinet |
Mode of motion | Grantry moving |
Machine Model | 8STC-1325HX |
Platform size | 1600x3100mm |
Working range | 1300x2500mm |
Z-axis range | 550mm |
Max Height of material | 750mm |
Machine Structure | 8mm thick heavy-duty tubular steel frame,full-welded,VSR |
Surface material | Thickend aluminum |
Fixturing method | T-slot for clamp fixture |
X,Y Transmission | Germany Slanting rack |
Z-axis Transmission | HIWIN 25 Ball Screw |
Rail configuration | HIWIN 25 Square guide rail |
Positioning accuracy | ±0.1/300mm |
Spindle speed | 0-24000(r/min) |
Y-axis dual drive | Stepper Motor LeiSai 110,Shenzhen |
X,Z axis drive | Stepper Motor LeiSai 110,Shenzhen |
Control System | NcStudion Control System of Shanghai |
Code Formats | G code,U00,mmg, nc |
Idle speed | 0-20000mm/Minute |
Working speed | 0-15000mm/Minuter |
Resolution | 0.00625/Minute |
Tool diameter | 3.175mm,4mm,6mm,8mm,10mm,12.7mm |
Spindle power | 4.5kw |
Cooling System | Water cooling |
Weight | 3100KGS |
Power | 380V50HZ±10(Internal Power) |
Electric Box | Intergrated computer control cabinet |
Mode of motion | Grantry moving |
A.Guarantee & Aftersales Service
12 months for the whole machine.
Within 12 months under normal use and maintenance,if something is wrong with machine,you will get spare part for free.
Out of 12 months,you will get spare part at cost price.
You will also get technical support and service all the lifetime.
B.Technical support:
Technical support by phone,email or MSN/Skype around the clock.
Friendly English version manual and operation video CD disk.
Engineer available to service machinery overseas
Free technician training for large customers
C.After sales services:
Normal machine is properly adjusted before dispatch.
You will be able to use the machines immediately.
You will be able to get free training advice towards our machine in our factory. You will also get free suggestion and consulting,technical support and service by email/fax/tel and lifetime technical support.
We started to produce Mechanical and Laser Engraving Machine in 1994. Nearly 20 years rich experience in producing saling and service ensures you high quality machine and perfect service. Our Export Percentage up to 81%~90%.
OEM Service Offered Design Service Offered Buyer Label Offered .
1. i like the machine and i made few work in wood so far. ; ) very happy ! ; ) see my first work ; )
------- jeffrey from Netherlands
2. we are very satisfied with your company and with your products. We believe that our market has a big sales potential for your products. We would be interested in cooperation with your company in a long term period. We would be happy to become an exclusive representative of your company in our country -----Eva
2. Oh!!!! my god!!!! thank you!!!! T-T VeryVeryVeryVeryVeryVeryVery~ thank you.--- Sa Hwan Pyo ( from south korea, we sloved one problem of his G code file he made. he is very excited to see the problem is sloved by our technist.)
3.I have ordered my machine it is the SM variant of the CNC 3040, which has marginally better specs than most. The machine comes powdercoated to stop oxidization from the factory.So far customer service
has been quite good via MSN & E-Mail and whats nice is the sales lady speaks very good english
too! (which isn't very common for most cheap exporting chinese companies).
------------- craig (from UK , he is very satisfied with our machine quality and service and introduced many customers to us. very thanksful to him )
How to choose a good machine:
1)Machine's quality,if you want to choose a cheap one.Maybe the quality is too bad.And you must buy the other one after you use it for a period of the time.This situation will influence your production.So the quality of the machine is so important than others.
2)Many times after-sales service is very important too.Good after-sales service representative the image of the company .After you use the machine and find some problem of machine in some respect.A good after-sales can dealing with it effectively and protect the rights of consumers.
3)The third is technical support.Because of time difference,When you need help,other place maybe is sleeping.So the effectively contact information and serve is also useful to you.
4)The last is company. In order to ensure their image ,good reputation company will produce
