XJ3030 Professional Mini Cnc Router

FOB Price

US$ 100 - 5,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	xyz-tech
Model Number	XJ3030

XJ3030 professional mini cnc router
1.DSP control system
2.USB interface
3.High efficiency
4.High precision

XJ3030 professional mini cnc router

Features:

1.High power water cooling brushless motor,more foreful cutting capability

2. Be compatible with Type 3, Artcut, Artcam, Mach3, CAD/CAM software

3. The lathe bed is wholly cast with iron to ensure high stability. Three axes all adopt linear square rail

4.High speed driver and stepper motor could enhance work efficinecy

Technical parameter

Technical parameter

X Y Z Working Area	300mm300mm80mm Z Strock can be higher
Drive mechanism	German imported ballscrew for x,y,z axis
Table Structure	T-Slot Extrusions
Table surface	PVC materials
Frame	Cast Iron
X Y Tansmission	Ball screw rod with Round Rail ,Optional:Rack gear, Square Rail.
Z Transmission	Rail linear bearing,Ball Screw Rod.Round Rail.Optional:Square Rail
Engavering accuracy	0.02-0.05mm
Reposition accuracy	0.02-0.05mm
Max air moving speed	8000mm/min
Max working speed	6000mm/min
Spindle Power	0.8KW water cooling spindle without brush.Optional:Self cooling Spindle.
Spindle Max Rotary Speed	24000r/min
Motors and Drivers	Stepper Motor and Driver(Optional:Servo Motor and Driver)
Working Valtage	AC220V/50HZ 3PH(Optional:380V)
Command Language	G c
Operating System	NcStudio PCI Card,Optional:DSP Panel
Interface	USB
Flash memory	128 U Disk
Spindle Collect	ER11-ER20
Running Environment	Temperature: 0°C~45°CRelative humidity: 30%~75%
Packing Tape	Wooden case
