Specifications
XJ1224 automatic CNC wood lathe*1200*2400mm working area
*Block cast fuselage
*CE authorized
*DSP control system
XJ1224 automatic CNC wood lathe
1.Technical parameters:
Model |
XJ-1224 |
|
Working Area |
advertising cnc router lathe 1200*2400mm 1,200×2,400×100mm |
|
Spindle Motor |
1.5KW Inverter-driven spindle motor cooled by water (or air for option) |
|
Working Mode |
Stepper motor |
|
Control System |
DSP(128MB) or PCIMC control system |
|
Drive Mechanism |
German imported ballscrew for x,y,z axis |
|
Table Surface |
T-slot extrusions |
|
Frame |
Cast wholely by Iron |
|
Motion Positioning Accuracy |
±0.02/300mm |
|
Repositioning Accuracy |
±0.01mm |
|
Max Motion Speed |
9,000mm/min |
|
Max Engraving Speed |
5,000mm/min |
|
Rotating Speed of Spindle |
2,4000rpm |
|
Engraving Tools |
3.175mm, 4mm 6.00mm |
|
Dictate Formate |
G code, *.u00, *.mmg, *.plt/HPGL/NC |
|
Operating Voltage |
AC220/50Hz |
|
Software |
Type3 original with Dongle or Wentai , ARTCAM/CAXA |
|
Packing Size |
**** |
|
Net Weight |
500kg |
|
Gross Weight |
567kg |
|
Noise Level |
Racing |
LAeep dB(A)72±1 |
Engraving |
LAeep dB(A)80±2 |
|
Engraving Peak |
LAeep dB(C)95 |
|
Optional Parts |
Dust Collecting System |
|
| ||
Rotary Device | ||
Mist Sprayer & Flume | ||
DSP System w/Portable Control Pad (128MB) | ||
2.Guarantee & Aftersales Service
Guarantee for one year,
24-hour technical support by email or calling .
User-friendly English manual for machine using and maintaining
