Guangzhou Double stations pneumatic heat transfer machine tshirt

Guangzhou Double stations pneumatic heat transfer machine tshirt

1.Voltage:380V/50Hz
2.temperature:0-339 degreeGuangzhou Double stations pneumatic heat transfer machine tshirt
3.use: for t-shirt/sportswear printing,  mouse pad, towel, aluminum plate, tiles etc

Voltage: 380V/50Hz, 3 phases, 4 lines

Temperature Range:0-399 C
Timing Range:0-999 Sec.

Brief introduction:

Semi Pneumatic Transfer Machine/Automatic Pneumatic Transfer Machine, can be sublimation type, solvent type ink color pattern hot and text

via thermal transfer on cotton, hemp, chemical fiber velvet material on the heat transfer and also for tufting foam printing process such as processing, economical and practical.

Feature:

Electronic digital thermostat control temperature, high accuracy (± 2 ℃);

Fever imported aluminum alloy casting thermal principle, power, temperature uniformity, temperature coefficient is small;

Electronic time control, process completion signal indication;

Pressure adjustable.

Specifications:

Technical characteristics:

1.       Adopt IC board ,touch buttons, electromagnetic switch and ON/OFF timer,providing elegant appearance and high reliability;

2.       Stable running,deforming free and low noise;

3.       Automatic control,even and stable pressure (pressure up to 8KG/CM2);

4.       Two optional running modes for work bench:manual and automatic;

5.       Dual-side pull type work bench saves labor and provides high printing speed;

6.       Using special security devices,the machine is anti-crushing,safe and rationalized;

7.       Surrounding design is adopted for special tube of heating panel,ensuring uniform heating;

8.       Specially treated working table is suitable for printing products for sublimation,heat transfer printing and gilding

Safety Precautions:

Machine must be placed on level ground, the operation must be preceded by appropriate protection of solid ground,

the machine must not touch the machine during operation at fever heat plate, the machine such as failure and the need to consult matters,

please contact your local dealer or the manufacturer.

More detail pictures:

1. transfer paper, solvent transfer paper, heat transfer vinyI

2. sublimation ink and solvent ink, sublimation coating

3.sublimation printer

4. roll heat press machine

5. small press machinery

6. sublimation printing for cotton fabric, t-shirt, sportswear, bag, ceramics and so on.
