Help CenterAutomatic Locating Laser Cutting Machine With Camera
Related Products
Specifications
1)automatic locating laser cutting machine with camera2)camera located to deal with picture automatically
automatic locating laser cutting machine with camera
advantages
1.First, the cameral get the edge of the objection that need to cut and extend (entad or forth) expected distance, and then cut them. According to common knowledge, the fabric labels may a little different from each other, and adoption of this technology can solve this problem.
2.Install 2-3 million pixel colorful camera. Can do accurately locating cutting for those edge-immovable objections. For example, it can accurately cut those distorted-not-much fabric labels.
3.It is for exact picture cutting, like fabric label, embroidery cutting and so on.
4.Adopt high quality CO2 laser tube, longer service life, the output is more stable.
Model |
JQ1515 |
Laser Power |
80W/130W |
Laser Type |
CO2 sealed, glass laser tube, water cooling |
Work Area |
1500 X 1500 mm |
Cooling Type |
Water-cooled and Protection System |
Engraving Scanning Speed |
0-60000 mm/min |
Cutting Speed |
0-1000mm/min |
Laser Output Control |
1-100% Software Setting |
Smallest Character Engraving |
English: 1.0X1.0 mm |
Highest Scanning Precision |
2500DPI |
Power Supply |
AC 110-220V±10%, 50-60Hz |
Operating Temperature |
0°-45°C |
Operating Humidity |
5%-95% |
Locating Precision |
≤±0.01mm |
Supported File Format |
DST,PLT,BMP,DXF,AI |
Compatible Software |
TAJIMA,CORELDRAW,PHOTOSHOP,AUTOCAD,All Type of AUTOCAD Software in cloth |
Slope Engraving |
360°Slope Can Be Designed Easily |
Driving System |
Servo Motor |
Package Dimension |
2160X1710X1300 mm |
Net Weight |
700KGS |
Gross Weight |
750KGS |
Optional Spare Parts |
Up-down Worktable, Rotary System, Honeycomb Worktable |
Removable Spare Parts |
Laser Tube and Lens |
Applicable Industries Garments sampling, large width tailoring, leather industry, shoemaking decoration, furniture, advertisement, packing and printing, molding and art craft industries, etc.
Applicable Materials
Fabrics, leather, paper. bamboo ware, acrylic, glass, films and canvas, wood, porcelain, acryl, cloth, etc.
Working principle of Auto locate cutting system:
1: Take photo of label.
2: Convert color photo to black-white photo.
3: Auto-find outlines then extend them
4: Select one of outline for cutting.
5: Use different extension.
6: Cut selected outline, then auto-process next label, repeat this progress for all labels.
