Home > Products > Metal laser cutting machine > JQ high precised quick speed fiber laser cutting machine 1000w
JQ high precised quick speed fiber laser cutting machine 1000w
- 100 Set / Sets per Month
- qingdao tianjin ningbo shanghai
- Credit Card
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | JQ |
Model Number: | 3015 | Voltage: | 220V/380V | Rated Power: | 20kw |
Dimension(L*W*H): | 7950*2100*1350 | Weight: | 3000kgs | Certification: | CE FDA |
Warranty: | 2 years | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
standerd export plywood package
Product Description
JQ high precised quick speed fiber laser cutting machine 1000w
1. machine is equiped with switching worktable, which could save time in big extent.
2. The power could be 2kW, 3KW, 4KW, and etc.
3. This machine is equiped with cover, which meet the demand of European safty standerd.
4. casted machine body guarantee the woking stability. So the cutting precision is much more precised.
5. imported parts to guarantee the cutting precision.
Except thismachine model, we also have the other two, swtching worktable. They are for huge working volume.
what's the features of fiber laser 1000W cutting sheet metal machinery?
1. automatic clamping, automaatic centering
2. forward and backward double driver can automatically clamping chuck, adjusable automatic V-shaped bracket
3. equip with high power panasoic servo motor
4. Zero waste materials can save more cost
5. whole machine performance is very stable
6. Low cost: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine.
7. Low maintenance: fiber line transmission no need reflect lens, save maintenance cost;
8. Easy operations: fiber line transmission, no adjustment of optical path.
what's the Technological parameters of fiber laser 1000W cutting sheet metal machinery?
Model | JQ-1530 |
Max. cutting length | 6m |
Laser generator | fiber laser |
Max. cutting diameter | 200mm |
Cutting thickness | 0.2mm-6mm steel/ 0.2-10mm stainless steel |
Laser wavelength | 1080nm |
Rated power | 10-100% |
Water chiller | Hanli |
X, Y-axis repeat location accuracy | 0.01mm |
X, Y-axis fast moving speed | 30M/min |
Min cutting line width | 0.02mm |
Max. cutting speed | 12M/min |
what's the materials application of fiber laser 1000W cutting sheet metal machinery?
Applicable to fast cutting on plate or tube in metal, mainly for cutting on SS, carbon steel, Manganese steel, galvanized plate, alloy plate, rare metal.
what's the available industries of fiber laser 1000W cutting sheet metal machinery?
Widely used in Aerospace navigation, kitchen applicance, electic control box, high-resolute device, mechanical equipment, electrical equipment, lighting, posters, auto parts, display equipment, hardware and metal processig
Company capacity:
Jinan JinQiang Laser CNC Equipment Co.,Ltd, located in the beautiful Spring City Jinan, was established in 2004. It is one of the most influential specialized manufacturers and suppliers of laser equipment in China. Now we have four workshop: Jinan, Linyi, Changqin, and Shanghai. All of the offices are devoted to give best after sales service to our customers.
Exhibition:
We will attend lots of affairs all over the world every month, America, Kore a, Russia, Middle Easte, Mexico, Thailand, India, Indonisia, and etc. Bellow i'm glad to share with you some of the pics:
Certificate:
With powerful R&D strength, being market-oriented, many years of experiment and practice, JQ LASER has developed a new advanced solid laser cutting system with large format and gantry structure. We are always on the way to develop new machines for meeting your demand. We will go forward together with the time.
How to pack and ship the machine
Packed with CE standard plywood case with steel pipe pallet.Firstly,there are for angle irons to fix the footstands(Casted iron,more stable). The five pieces of package is from inside to outside.Preservative film--- Foam --- Preservative film --- Plywood case --- Enlace steel bel t --- Paint the mark --- Foam(avoid damp) --- Over preservative film (avoid damp)
what's the after sales service of fiber laser 1000W cutting sheet metal machinery?
1. Two years guarantee of the whole machine.
2. CE and FDA certificate,the machines are produced according to standard.
3. We have excellent egineers speaking English,they can go to your country to solve your questions of machine you can't solve.
4. 24 hours internet service by sending emails and Videos,communicating online or calling.Door to door technical group service. English software, user manual and detailed Videos CD.
FAQ
1. Q:Are you a factory or trading company?
A: We are a factory
2. Q:Where is your factory located? How can I visit there?
A:Our factory is located in Jinan City, Shandong Province, China, about 4 hours train from Shanghai .
All our clients, from home or abroad, are warmly welcome to visit us!
3. Q:How can I get some samples?
A: We are honored to offer you samples.
4. Q:How does your factory do regarding quality control?
A:Quality is priority. JQ people always attach great importance to quality controlling
from the very beginning to the very end.
Our products have gained CE, FDA authentication.
Company Profile
Jinan JinQiang Laser CNC Equipment Co.,Ltd is located in Jinan High & New Technology Industrial Development Zone. We are committed ourselves to developing, producing and selling laser equipment. Our company supplies JQ series of laser engraving and laser cutting equipment, laser engravers and laser cutters. They are used in many fields. With high quality products and top after-sales service, we have won trust and support of customers from all over the world.
Our company is guided by the market-oriented concept as well as masterful technique, and regards "good service and customers' benefits" our rules. With technical development, and many years of research, our products are improved day by day.
Our philosophy is "Golden Quality, The Best Technique and Good Faith". We are trying to be a well-known company at home and abroad with the perfect and considerate after-sales service system.
We welcome customers from all over the world to cooperate with us. Please feel free to contact us for further information.
Selecting JQ laser the world will become yours !
