bottle laser cutting machine with CE
Welcome to visit our company------JQ LASER!!!
Machine Parameters
Laser power : | 80 W/100w/150w |
Laser tube life Span | 2500hours/4000hours/5000hours |
Applicable Materials | Acrylic,Glass,crystal,wood,leather,cloth,rubber,marble,ceramic,etc. |
Working area: | 900*600 mm |
Max moving speed: | 1500mm/s |
Laser energy control: | 1-100set by hand or software |
Worktable: | Fixed honeycomb table or knife table |
Locating precision: | 0.01 mm |
Min shaping character: | 0.01mm |
Operating temperature: | 5°C-35°C |
Resolution | 4500 dpi |
Laser type: | Hermetic CO2 glass tube |
Power supply: | AC220±1050 HZ/AC110±1050 HZ |
Control configuration: | DSP. |
Data transfer interface: | USB (offline). |
USB Ports | 2 |
System environment: | WINDOWS 2000/WINDOWS XP/MAC/Vista/W7 |
Cooling way: | Water cooling and protection system |
Graphic format supported: | The file which CorelDraw, Photoshop, AutoCAD can identify(BMP,GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG, DXP,PAT,CDT,CLK,DEX,CSL,CMX,AI,WPG,WMF,EMF,CGM,SVG,SVGZ,PCT,FMV,GEM,CMX). |
USER MENU | Full English. |
Package Inclusion | Software,VIDEO USER MENU CD,Air pump gun,Power cables, USB cables, Water tank,Water Pipe,Smoke Vent-pipe,Air Blow Pipe ,exhaust fan,Tools bag |
Memory | 64 MB |
Display screen | LCD(SIZE 70*40 mm) |
Protection System | Yes |
Option parts | high-grade cooling system/double-head/cylinder rotary Jig/ irregular rotary Jig/ up&down table/ knifes table |
Guarantee | 2 years |
Dimensions | 1.35*0.99*0.97m |
Dimensions(package) | 1.46*1.3*1.23m |
Net Weight | 250KGs |
Gross Weight | 300KGs |
Recommended Ship way | Sea /air/road |
Performance Features
1. Configure higher power laser tube.
2. DSP controlling system, rich functions, can effect engraving on plane, gradient engraving by 360 degree, cutting and drilling holes etc.
3.Owns functions of restoring from power off, continuation on break point.
4. Transmit files directly in CorelDraw, AutoCAD etc.
5.Adopt international linear rail, more precision.
Applicable materials
leather, cloth, wool, fur, acrylic, plexiglass, wooden board, plastic, resin and other non-materials.
Applicable industry
processing industries of lager scale engraving and cutting, such as garment, leather, clipping, cutting of template, package and printing, advertisement decoration, building upholster, art gift, computer embroidery, paper product, acrylic product, middle density board ect . non-metal sheet precision cutting and other industries.
Machine Parts
Sample Show
Certificate Show
