SUDA FIBER LASER MACHINE

Name: SUDA FIBER LASER MACHINE
Brand: suda
Price: USD $82,800.36 - 90,000.39 / Set

FOB Price

USD $82,800.36 - $90,000.39 / Set

1 Set(Min.Order)

Supply Ability 50 Set / Sets per Month
Port shanghai
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Laser Type:	Fiber Laser	Applicable Material:	Metal
Cutting Thickness:	<=10mm	Cutting Area:	1300*2500mm	Cutting Speed:	15-20m/min
CNC or Not:	Yes	Cooling Mode:	Water Cooling	Control Software:	YASKAWA
Place of Origin:	Anhui, China	Brand Name:	suda	Model Number:	FC1630
Certification:	CE, ISO	After-sales Service Provided:	Engineers available to service machinery overseas

Packaging Details

plywood

Product Description

Specifications

Japan YASKAWA servo motor
THK linear
asph

FIBER LASER MACHINE

Model Features

1: industrialized welded machine structure, milled by high accuracy planning machine,aneatment is made after , strong and stable machine structure can be assured during long time operating.

2:adopt japan THK linear & grinding ball screw

3:adopt Japan YASKAWA servo system

4:automatically-tracing smoking extraction system ,energy-saving and prefect smoke extraction effect .

5:configuration with inductive cutting head and mirror to reach as much as smaller focus spot as

6:optional fiber transmission ,flexible processing, cutting quality at any point can be ensured.

7:professional laser CNC control system, computer operation , more simple operation.

8:configuration with a variety of software, can design all kinds of graphics or text instant cutting, simple operation,flexible ,convenient.

9:with intelligent discharging function, material utilization rate is higher.

Application

Widely used in sheet metal process production of advertising signs ,kitchenware , hardware,lighting hardware,saw blade,eyes,machinery parts and other industries.

Technical date

Model Type	FC1325	FC1630	FC1640
Laser Media	Nd:FIBER	Nd:FIBER	Nd:FIBER
Power	Standard 500W Optional 300W/1000W	Standard 500W Optional 300W/1000W	Standard 500W Optional 300W/1000W
Wave Lenth	1080nm	1080nm	1080nm
Min.Route Width	0.1mm	0.1mm	0.1mm
Reposition Accuracy	±0.05mm	±0.05mm	±0.05mm
Cutting Width	1300x2500	1600x3000	1600x4000
Cutting Thickness	≤8mm	≤8mm	≤8mm
Aiming Positioning	Red Dot	Red Dot	Red Dot
Voltage Requirement	380v/50hz	380v/50hz	380v/50hz
Cooling Way	Water Cooling	Water Cooling	Water Cooling

THE COLOR OF THE MACHINE ,YOU CAN CHOSE !

IF YOU HAVE ANY NEEDS OR PROBLEMS ABOUT THIS MACHINE, PLS :

SKYPE: yoyo.yuan6

QQ:2362965390
