Specifications
Precise SD 1208 CNC Router Advertising Machine INTEGRAL CAST-IRON FRAME ,ROLLING BALL SCREW FROM GERMANY
CE
Precise SD 1218 CNC Router Advertising Machine
First,advantage of products
Stiff: integral cast-iron frame,embedded linear,much more stable and solid
Accuracy: rolling ball screw from Germany,two nut eliminating clearance,advanced fixing mode of three bearings
Strong: configured 2.2KW inverter-driven spindle motor cooled by water
Superior: adopt the most advanced DSP controlling system
Second,application
l
brands,seals,metal foil moulds,construction models,instrument panel and industrial moulds or dies on the materials such as many metal or non-metal material,for example,iron,copper,plastic and wood plates,etc.
Thrid,distinguished features
High speed: can process curves and straight lines simultaneously at t he speed of 12m/min (optional)
Large memory:standard allocation of 128M which can save 30 processing files simultaneously for your choice
Quick transmitting:Adopt advanced USB interface,can work without computer,not occupy any resources
Multi- compatibility:Be compatible with various CAD/CAM software such as Type3 /Artcam/Casmate/CAXA/Artgrave
Convenient operatiion:Owning the functin of restoring from power off,continuation on break point,anticipating working time,auto-feeding blades,friendly designing
Last,technical data
Model |
SD8070 |
SD1212 |
SD1218 |
SD1325 |
SD1630 |
SD2030. |
Working Area |
700*800*90mm |
1200*1200*90mm |
1200*1800*90mm |
1250*2500*90mm |
1550*3000*90mm |
2000*3000*90mm |
Spindle Motor |
2.2KW inverter-driven spindle motor cooled by water |
|||||
Engraving Speed |
6000-1200mm/min |
|||||
Rotation Speed of Spindle |
6000-24000rpm |
|||||
Engraving Tool |
3.175, 4, 6 (optional) |
|||||
Format Dictate |
HPGL,G-code |
|||||
Ball Screw |
Two-nut rolling ball screw from Germany |
|||||
Resolution |
0.01mm |
|||||
Optional:
water cooling system
Dust collecting system
Vacuum system
