Home > Products > SUDA Newest machine and model > Sell SUDA Mini Desktop CNC Router--SD3025V ( NEW MODEL)
Sell SUDA Mini Desktop CNC Router--SD3025V ( NEW MODEL)
- 1000 Unit / Units per Month
- shanghai
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Anhui, China | |
| Brand Name | SUDA ,Can OEM | Model Number | SD3025vV | |
| Rated Power | 220V | Engraving Speed | 8M/MIN | |
| Main Axle Rotational Speed | 24000RPM | Feeding Height | 40MM | |
| Milling Cutter Diameter | 3.175,6mm | Application | 300*250*40 | |
| Dimensions | 300*250*40mm working area | Weight | 195KGS | |
| Certification | CE,ISO | After-sales Service Provided | Engineers available to service machinery overseas |
non-wooden packages
Product Description
Specifications
Mini working size 300*250mmRolling ball screw from Germany
Durable and easy operation
Type3 software
CE certificate
Sell SUDA Mini Desktop CNC Router--SD3025V ( NEW MODEL)
Model | SD3025V |
XYZ Guide | Rolling ball screw from Germany,X,Y,Z axis all configured with imported Linear rail,more processing accuracy . |
Table size (cm) | 30*25 |
X Y Z Guide | Rolling ball screw from Germany,X,Y,Z axis all configured with imported Linear rail,more processing accuracy . |
XYZ movement (mm) | 300 x 250 x 60 |
Spindle power | 1500W |
Spindle speed (min/max) | 6000 - 24000 U/Min. |
Machine dimension (cm) | 56*54*59 |
Packing dimension (cm) | 66*64*69 |
Weight (kg) | 195KG |
Power consumption without spindle |
|
Speed max. | 0-70mm/s |
Working speed max. | 70mm/s |
Stepper or servo motor? | Stepping motor |
XYZ accuracy | 0,02mm |
Reposition accuracy | 0,01mm |
XY resolution | 0,01mm |
Z resolution | 0,01mm |
Table surface | Aluminum |
XY drive configuration | roll screws |
Z drive configuration | roll screws |
Included Software | Type3 V4.3 english |
Software Compatible with | Win98/Win2000/XP |
Spindle coolin system | water cooled |
Spindle collet | ER11 |
Software transmission language | G-Code, HPGL |
Interface | Transimt the file from USB flask disk directly |
Voltage | 220VAC/50-60Hz |
Running environment | 0-35°C, humidity: 10-70% |
Production time | 10 working days when we received all the payment by T/T |
Company Profile
Tongxing Technology Development Co., Ltd. is located in one of the Chinese Science & Technology Cities, Hefei City. Since foundation in 1992, we have been researching and developing digital products in advertising and mould processing, and have been a very manufacturer in advertising equipment. Our main products range is as follows: Suda vanguard series CNC engraver, Suda powerful CNC engraver, Suda luck series CNC engraver, Suda laser engraver, Suda cutting plotter, Suda afflatus cylinder CNC engraver, Suda plasma cutting machine. We have superior staff adhering to the motto of Sincere Operation. The style of designing delicate products has been accepted by customers both at home and abroad. Our products have been exported to many countries and regions such as South-east Area, the Middle East, Europe and America. Tongxing is willing to cooperating with you based on mutual benefits based on brilliant future.
Contact Us
- Tongxing Technology Development Co., Ltd.
- Contact nameSnail Hu Chat Now
- Phone86-551-66370766
- AddressFenglin Boulevard, Shuangfeng Developing Area, Hefei City, Anhui Province. China, Hefei, Anhui
