Suda 3025SU Mini Cnc Machine Decorative Iron Tools

Name: Suda 3025SU Mini Cnc Machine Decorative Iron Tools
Brand: SUDA
SKU: 144391368

Negotiable MOQ: 1 Short Ton (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Anhui, China

Brand Name:

SUDA

Model Number:

SD3025S

Tongxing Technology Development Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Anhui, China

Brand Name SUDA

Model Number SD3025S

Rated Power 220V

Engraving Speed 6M.MIN

Main Axle Rotational Speed 24000

Feeding Height 40

Milling Cutter Diameter 3.175 6

Application WOODWORKING,METAL

Dimensions 300*250*40

Weight 95KGS

Specifications

3025S mini cnc machine
Integral cast-iron frame
Rolling ball screw made in Germany
Widely application
CE

SD3025SU

1. Detailed Product Description

Model	SD3025SU
XY Guide	Rolling ball screw from Germany
Table size (cm)	30*25
Z Guide	Rolling ball screw from Germany
XYZ movement (mm)	300 x 250 x 40
Spindle power	800W
Spindle speed (min/max)	6000 - 24000 U/Min.
Machine dimension (cm)	565459
Packing dimension (cm)	666469
Weight (kg)	90KG
Power consumption without spindle
Speed max.	0-70mm/s
Working speed max.	70mm/s
Stepper or servo motor?	Stepping motor
XYZ accuracy	0,04mm
Reposition accuracy	0,01mm
XY resolution	0,025mm
Z resolution	0,025mm
Table surface	Aluminum
XY drive configuration	roll screws
Z drive configuration	roll screws
Included Software	Type3 V4.3 english
Software Compatible with	Win98/Win2000/XP
Spindle cooling system	water cooled
Spindle collet	ER11
Software transmission language	G-Code, HPGL
Interface	Transimt the file from the computer directly
Voltage	220VAC/50-60Hz
Running environment	0-35°C, humidity: 10-70%
Production time	10 working days when we received all the payment by T/T
