HEFEI SUDA CNC CENTER SELL 3025V mini cnc engraving machine
Model |
SD3025V(also can called SD3025MV,same machine) |
XY Guide |
Rolling ball screw from Germany and imported linear rail to keep more accuracy |
Table size (cm) |
30*25 |
Z Guide |
Rolling ball screw from Germany and imported linear rail to keep more accuracy |
XYZ movement (mm) |
300 x 250 x 60 |
Spindle power |
1500W BOL AIR COOLING |
Spindle speed (min/max) |
6000 - 24000 U/Min. |
Machine dimension (cm) |
56*54*69 |
Packing dimension (cm) |
Machine body-640*620*670;controller 460*410*1120;machine cabinet770*770*820 |
Weight (kg) |
185KGS |
Power consumption without spindle |
More than 1000W |
Speed max. |
0-100mm/s |
Working speed max. |
100mm/s |
Stepper or servo motor? |
Stepping motor |
XYZ accuracy |
0,04mm |
Reposition accuracy |
0,01mm |
XY resolution |
0,025mm |
Z resolution |
0,025mm |
Table surface |
Cast iron table which with water cooling system |
Inveter |
Danfoss holip frequency converter from Denmark |
XY drive configuration |
roll screws |
Z drive configuration |
roll screws |
Software Compatible with |
Win98/Win2000/XP |
Spindle cooling system |
air cooled |
Spindle collet |
ER11 |
Tools |
10pcs for engraving and cutting &milling |
Control system |
CNC Controlling system :/SUDA coloured handle,4GB INNER MEMORY |
Software transmission language |
G-Code, HPGL |
Interface |
Transmit the file from network cable |
Voltage |
220VAC/50-60Hz |
Running environment |
0-35°C, humidity: 10-70% |
Production time |
One week when we received all the payment by T/T |
Colour |
Can optional |
Guarantee & Aftersale Service:
1.Guarantee for one year
2.24-hour technical support by email or on line
3.User-friendly English manual for machine using and maintaining
4.Free technician training for large customers.
5. Provide Engineers oversea training for our customers .
TONGXING TECHNOLOGY DEVELOPMENT Co., LTD. Lines in one of Chinese science and technology cities-Hefei. It has been researching and manufacturing the CNC machinery for advertising making and mould processing since 1992.
Great deals of scientific and technical talents supply a fertile soil for the developing of technology manufacturing industry. With the rapid economic growth in China, the science and technology city- Hefei, is growing into one of the cities with greatest development potential.
Up to date, Tongxing company owns three production bases and one national advanced CNC Laboratory, which sum to 80,000 square meters.
Tongxing always pursue the two conceptions “Supply Excellent Products” and “Create Value for Customers”, which has been recognized both in and outside China.The main products are as follows: Suda Vanguard Series large format CNC Engravers, Suda Powerful series CNC engravers, Suda Luck Series CNC engravers, Suda speedy CNC Engravers, Suda Cutting Plotter, Suda Laser Machine and Suda Cylinder CNC Engraver, total 16 series, mote than 70 models.
The main products especially Suda Large Format CNC Router-which is the first National big format CNC Router in the market have been awarded “High & New Technology Products” by the government, at the same time, Tongxing Company is voted as “State Level High-tech Enterprise”.
Our marketing network has covered all Chinese provinces and municipalities, including Hong Kong ,Taiwan & Macao besides Main Land. Till now, Suda products have been exported to more than 100 countries and regions like Russia, Japan, South-east Asia, Mid-east, Europe and America etc.
Q1.How do you get the best price?
As you may know,the different type of CNC machine apply to the different material,and the different model apply to the different material.
Please tell me what’s material you want to cutting or engraving ?
And what’s MAX size of carved material ?
Then I wil recommand the most suitable model and the best price for you.
Q2.In case of failure,how to do?
Call us----our enginners are online for 24-hours,and ready to serve you.
Replacement of damaged parts for free---For more information,please contact us
The CD and operation manual----It show the most common failure in working processing and how to solve this problems.
